How to Install
NOTE!
Note the plinth is provided in the same packaging as the filter, but is not always attached to frame during shipment. The
plinth is required to allow airflow to the unit to provide proper cooling. The plinth of the D and E-frames filters should be
mounted before the unit is lifted to its final position.

4.2.5 Mechanical Dimensions

4 4
1733,6
[68]
200.0
[8]
Figure 4.4 Frame size D9, AAF05
4-4
VLT Active Filter AAF 00x
1553,4
[61]
840
®
MG.90.V2.22 - VLT
1853,6
[73]
377,8
[15]
