Specifications

7.3 Power Loss and Acoustic Noise Level

Table 7.3 explains in detail the terminology used in the power loss and acoustic noise level tables. See Table 7.4 to Table 7.8.
Value
Current rating
Order numbers
AHF 005
AHF 010
Power loss
Acoustic noise level
Table 7.3 Terminology in Power Loss and Acoustic Noise Level Tables
NOTICE
The tables in chapter 7.3 Power Loss and Acoustic Noise Level are only valid for VLT
005/AHF 010 revision 03.
380–
415 V
50 Hz
Power loss at percentage load of
Current Order
rating number
0% 25%
[A] [P/N]
[W]
10 130B1229 28
14 130B1231 37
22 130B1232 59
29 130B1233 75
34 130B1238 79
40 130B1239 81
55 130B1240 73
66 130B1241 96
82 130B1247 100
96 130B1248 117
133 130B1249 127
171 130B1250 159
204 130B1251 214
251 130B1258 291
304 130B1259 292
325 130B3152 267
381 130B1260 282
480 130B1261 408
Table 7.4 Power Loss and Acoustic Noise Level, 380–415 V, 50 Hz
MG80C602
Design Guide
Description
Filter nominal current rating
AHF part number for ordering.
AHF version with performance level of 5% THDi or better at system level with nominal load
AHF version with performance level of 10% THDi or better at system level with nominal load
Power loss according to EN50598 Ecodesign for PDS at percentage load (0, 25, 50, 75, 100) of
nominal current. The power loss references are with 25 °C (77 °F) ambient temperatue
Maximum acoustical noise level from filter at 1 m (3.28 ft)distance with nominal loading at
25°C (77°F) ambient temperature. Maximum level typical at nominal loading.
AHF 005
Acoustic
nominal current
50% 75% 100%
[W] [W] [W] [W]
36 66 91 142
56 85 132 177
84 129 202 286
106 165 259 357
112 189 296 425
122 202 311 457
117 217 361 541
163 288 478 717
171 296 491 733
177 305 477 699
211 356 581 873
272 493 823 1215
318 527 837 1253
322 556 896 1366
407 662 991 1505
395 679 1083 1656
416 718 1265 2009
604 1039 1848 2623
Danfoss A/S © 05/2019 All rights reserved.
®
Advanced Harmonic Filter AHF
Power loss at percentage load of
Order
noise number
0% 25%
[dB(A)] [P/N]
[W] [W]
< 70 130B1027 17 22
< 70 130B1058 36 50
< 70 130B1059 52 73
< 70 130B1089 65 87
< 72 130B1094 60 83
< 72 130B1111 57 86
< 72 130B1176 59 92
< 72 130B1180 71 117
< 72 130B1201 83 125
< 75 130B1204 108 157
< 75 130B1207 117 185
< 75 130B1213 141 227
< 75 130B1214 146 231
< 75 130B1215 197 312
< 75 130B1216 240 361
< 75 130B3136 252 367
< 75 130B1217 279 386
< 77 130B1228 390 593
AHF 010
Acoustic
nominal current
noise
50% 75% 100%
[dB(A)]
[W] [W] [W]
38 54 86 < 70
72 106 137 < 70
110 165 229 < 70
127 188 248 < 70
129 203 285 < 72
142 214 317 < 72
160 259 387 < 72
201 334 512 < 72
197 302 447 < 72
254 385 554 < 75
307 493 737 < 75
375 593 895 < 75
380 598 905 < 75
504 786 1194 < 75
584 880 1352 < 75
593 921 1385 < 75
676 1072 1617 < 75
984 1616 2347 < 77
