7.5 Fuses

To protect the installation against electrical and fire hazards, all filters in an installation must be protected against short-
circuiting and overcurrent according to national and international regulations.
To protect both frequency converter and filter, select the type of fuses recommended in the frequency converter design
guide. The maximum fuse rating per filter size is listed in Table 7.24 to Table 7.27.
Filter current rating
[A]
10
14
22
29
34
40
55
66
82
96
133
171
204
251
304
325
381
480
Table 7.24 380–415 V, 50 Hz and 60 Hz
Filter current rating
[A]
10
14
19
25
31
36
48
60
73
95
118
154
183
231
291
355
380
436
Table 7.25 440–480 V, 60 Hz
1) Specified type is a UL requirement.
MG80C602
Design Guide
Maximum fuse size
[A]
16
35
35
50
50
63
80
125
160
250
250
315
350
400
500
630
630
800
Maximum fuse size
[A]
20
35
35
50
50
60
80
125
150
250
250
300
350
400
600
600
600
600
