Specifications
429±2.5 mm [16.9±0.10 in]
Ø20.5 mm [0.8 in]
Ø40 mm [1.6 in]
Ø40 mm [1.6 in]
Ø40 mm [1.6 in]
468±2.5 mm [18.4±0.10 in]
Illustration 7.46 IP21 X7-V3 Internal and External Fan
Illustration 7.47 IP21 X7-V3 Internal and External Fan, 3D View
MG80C602
Design Guide
800±2.5 mm [31.5±0.10 in]
313.3±2.5 mm [12.3±0.10 in]
1196.8±2.5 mm [14.6±0.10 in]
240±2.5 mm [9.4±0.10 in]
323±2.5 mm [12.7±0.10 in] 300±2.5 mm [11.8±0.10 in]
Danfoss A/S © 05/2019 All rights reserved.
83.8±2.5 mm [3.3±0.10 in]
240±2.5 mm [9.4±0.10 in]
93.8±1.0 mm [3.7±0.04 in]
