Danfoss AHF 010 Design Manual page 69

Specifications
PE M6 (10Nm)
46.5±1.0 mm [1.8± 0.04 in]
6.5±1.0 mm [0.3± 0.04 in]
Illustration 7.6 IP20 X2-V3 Internal Fan
X1 Mains 10mm (2.4Nm)
X2 Drive 10mm (2.4Nm)
Illustration 7.7 IP20 X2-V3 Internal Fan, Terminal Designation and 3D View
MG80C602
Design Guide
350.0±1.0 mm [13.8± 0.04 in]
382.0±1.0 mm [15.0± 0.04 in]
399.0±1.0 mm [15.7± 0.04 in]
434.5± 2.5 mm [17.1± 0.10 in]
X3/X4 Capacitor disconnect 2.5mm (0.8Nm)
A/B Temperature 2.5mm (0.8Nm)
Danfoss A/S © 05/2019 All rights reserved.
232.0±1.0 mm [9.1± 0.04 in]
6.0±1.0 mm [0.2± 0.04 in]
7 7
67
