Danfoss AHF 010 Design Manual page 111

Spare Parts
380–415 V/60 Hz
AHF 010
Current
Enclosure
Quantity
rating
1) required
type
[A]
10 X1-V3 IP20 if 0
14 X1-V3 IP20 ef 1
22 X2-V3 IP20 if 1
29 X2-V3 IP20 if 1
34 X3-V3 IP20 if 1
40 X3-V3 IP20 if 1
55 X3-V3 IP20 if 1
66 X4-V3 IP20 if 1
82 X4-V3 IP20 ef 1
96 X5-V3 IP20 ef 1
133 X5-V3 IP20 ef 1
171 X6-V3 IP20 if 1
204 X6-V3 IP20 if 1
251 X7-V3 IP20 if 2
304 X7-V3 IP20 if 2
325 X7-V3 IP20 ef 2
381 X7-V3 IP20 ef 2
480 X8-V3 IP20 ef 2
Table 8.22 Fan Kits and Accessories for AHF 010, 380–415 V, 60 Hz
1) Note, enclosure types with internal fan has the fan fence integrated in the cabinet.
2) 10 A version is cooled by natural convections.
MG80C602
Design Guide
Valid only for AHF 010 revision 03
Fan
Order
Quantity
number Description
required
[P/N]
– 2) 0
1
0
0
0
0
0
0
1
1
AHF3 fan
175U0338
1
24 V DC
0
0
0
0
2
2
2
