Danfoss AHF 010 Design Manual page 98

Spare Parts
600 V, 60 Hz
Current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
8 8
395
Table 8.4 Capacitor Kits, 600 V, 60 Hz
500–690 V, 50 Hz
Current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 8.5 Capacitor Kits, 500–690 V, 50 Hz
96
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Valid for AHF revisions 01 and 02
Order number
[P/N]
175U0205
175U0206
175U0207
175U0208
175U0209
175U0211
175U0212
175U0213
175U0214
175U0215
175U0217
175U0218
175U0219
175U0245
175U0254
175U0255
175U0256
Valid for AHF revisions 01 and 02
Order number
[P/N]
175U0173
175U0174
175U0175
175U0176
175U0177
175U0178
175U0180
175U0190
175U0193
175U0195
175U0196
175U0197
175U0198
175U0199
175U0201
175U0202
175U0203
Danfoss A/S © 05/2019 All rights reserved.
Capacitor kit
Description
Capacitor Bank AHF2 DA/B 600V-60Hz-015A
Capacitor Bank AHF2 DA/B 600V-60Hz-020A
Capacitor Bank AHF2 DA/B 600V-60Hz-024A
Capacitor Bank AHF2 DA/B 600V-60Hz-029A
Capacitor Bank AHF2 DA/B 600V-60Hz-036A
Capacitor Bank AHF2 DA/B 600V-60Hz-050A
Capacitor Bank AHF2 DA/B 600V-60Hz-058A
Capacitor Bank AHF2 DA/B 600V-60Hz-077A
Capacitor Bank AHF2 DA/B 600V-60Hz-087A
Capacitor Bank AHF2 DA/B 600V-60Hz-109A
Capacitor Bank AHF2 DA/B 600V-60Hz-128A
Capacitor Bank AHF2 DA/B 600V-60Hz-155A
Capacitor Bank AHF2 DA/B 600V-60Hz-197A
Capacitor Bank AHF2 DA/B 600V-60Hz-240A
Capacitor Bank AHF2 DA/B 600V-60Hz-296A
Capacitor Bank AHF2 DA 600V-60Hz-366A
Capacitor Bank AHF2 DA 600V-60Hz-395A
Capacitor kit
Description
Capacitor bank AHF2 DA/B 500V/690V-50Hz-015A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-020A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-024A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-029A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-036A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-050A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-058A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-077A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-087A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-109A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-128A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-155A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-197A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-240A
Capacitor bank AHF2 DA/B 500V/690V-50Hz-296A
Capacitor bank AHF2 DA 500V/690V-50Hz-366A
Capacitor bank AHF2 DA 500V/690V-50Hz-395A
MG80C602
