Danfoss AHF 010 Design Manual page 60

Specifications
600 V
60 Hz
Current
rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
7 7
197
240
296
366
395
Table 7.16 AHF 010: 600 V, 60 Hz
500–690 V
50 Hz
Current
rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 7.17 AHF 005: 500–690 V, 50 Hz
58
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Order
number Height
[P/N] [mm (in)]
130B5212 592 (23.3)
130B5213 592 (23.3)
130B5214 593 (23.4)
130B5215 621 (24.5)
130B5216 621 (24.5)
130B5217 736 (29)
130B5218 736 (29)
130B5219 764 (30.1)
130B5220 764 (30.1)
130B5221 764 (30.1)
130B5222 764 (30.1)
130B5223 957 (37.7)
130B5224 957 (37.7)
130B5225 957 (37.7)
130B5226 957 (37.7)
130B5227 957 (37.7)
130B5228 957 (37.7)
Order
number
Height
[P/N]
[mm (in)]
130B5088 592 (23.3)
130B5089 592 (23.3)
130B5090 593 (23.4)
130B5092 621 (24.5)
130B5125 621 (24.5)
130B5144 736 (29)
130B5168 736 (29)
130B5169 764 (30.1)
130B5170 764 (30.1)
130B5172 764 (30.1)
130B5195 764 (30.1)
130B5196 957 (37.7)
130B5197 957 (37.7)
130B5198 957 (37.7)
130B5199 957 (37.7)
– –
– –
Danfoss A/S © 05/2019 All rights reserved.
AHF 010
Dimensions
Width Depth
[mm (in)] [mm (in)]
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 338 (13.3)
378 (14.9) 338 (13.3)
418 (16.5) 333 (13.1)
418 (16.5) 333 (13.1)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
AHF 005
Dimensions
Width Depth
[mm (in)] [mm (in)]
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 338 (13.3)
378 (14.9) 338 (13.3)
418 (16.5) 333 (13.1)
418 (16.5) 333 (13.1)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
– –
– –
Weight Enclosure
[kg (lb)] type
25 (55) X3-V3 IP20 if
36 (79) X3-V3 IP20 if
40 (88) X3-V3 IP20 ef
42 (93) X4-V3 IP20 ef
52 (115) X4-V3 IP20 ef
56 (123) X5-V3 IP20 ef
62 (137) X5-V3 IP20 ef
74 (163) X6-V3 IP20 ef
85 (187) X6-V3 IP20 ef
105 (231) X6-V3 IP20 ef
123 (271) X6-V3 IP20 ef
136 (300) X7-V3 IP20 ef
142 (313) X7-V3 IP20 ef
163 (359) X7-V3 IP20 ef
205 (452) X8-V3 IP20 ef
228 (503) X8-V3 IP20 ef
260 (573) X8-V3 IP20 ef
Weight Enclosure
[kg (lb)] type
42 (93) X3-V3 IP20 if
50 (110) X3-V3 IP20 if
52 (115) X3-V3 IP20 ef
75 (165) X4-V3 IP20 ef
82 (181) X4-V3 IP20 ef
96 (212) X5-V3 IP20 ef
104 (229) X5-V3 IP20 ef
130 (287) X6-V3 IP20 ef
135 (298) X6-V3 IP20 ef
168 (370) X6-V3 IP20 ef
197 (434) X6-V3 IP20 ef
220 (485) X7-V3 IP20 ef
228 (503) X7-V3 IP20 ef
261 (575) X8-V3 IP20 ef
297 (655) X8-V3 IP20 ef
– –
– –
MG80C602
