Installation Guide
Advanced Active Filter AAF 007
drives.danfoss.com |

Advertisement

loading
Need help?

Need help?

Do you have a question about the AAF 007 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Danfoss AAF 007

  • Page 1 Installation Guide Advanced Active Filter AAF 007 drives.danfoss.com |...
  • Page 3 Installation Guide | Advanced Active Filter AAF 007 Contents Contents Instructions Safety and Installation Awareness Intended Use Required Tools Electrical and Mechanical Ratings Verifying the Shipment and the Contents Installing the Filter Parallel Installation Current Transformers Serial Communication Four-wire System 1.10...
  • Page 4 Installation Guide | Advanced Active Filter AAF 007 Contents | Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283...
  • Page 5 Intended Use The Advanced Active Filter AAF 007 is intended to be used in electrical installations to improve power quality. To achieve an improved power quality, the filter injects currents in counter-phase to mitigate distortions on the grid.
  • Page 6 Installation Guide | Advanced Active Filter AAF 007 Instructions Verifying the Shipment and the Contents Ensure that the items supplied and the information on the nameplate correspond to the order confirmation. The filter module label is on the top of each filter module.
  • Page 7 Ensure the right position of the CT according to the setting in the filter. Load side or grid side. Routing of wires: The wires between AAF 007 and the current transformers must be twisted pair cables. A correct function is only possible if the wiring exactly matches the upper diagram in step 7 in the Illustrations section. If wires are interchanged, the harmonics are not to be reduced, but amplified.
  • Page 8 When the filter is connected to mains, it will start operation. Check that the wiring is correct by assessment of the improvement of the power quality either with the PC tool for filter or with a power quality meter. Consult Advanced Active Filter AAF 007 Operating Guide for further information.
  • Page 9 Installation Guide | Advanced Active Filter AAF 007 Instructions S = Power of the current transformer (typically 2.5 VA) d = Distance (length of cableway) between filter and current transformer v = Twisting factor (typically 1.5) I = Secondary current of the current transformer (typically 5 A) ρ...
  • Page 10 Installation Guide | Advanced Active Filter AAF 007 Instructions Power Losses and Efficiency 1.11 For power loss data including part load losses, see https://ecosmart.mydrive.danfoss.com. Cable and Fuse Specifications 1.12 The filter is protected internally with semiconductor fuses. Branch protection is subject to local installation conditions and regulations, and thus no recommendations can be made.
  • Page 11 Installation Guide | Advanced Active Filter AAF 007 Instructions Table 1: Cable and Fuse Specifications (continued) Enclosure AAF01 AAF02 Current 35 A module 55 A module 100 A module 150 A module Control cables 1 mm (17 AWG) 1 mm (17 AWG)
  • Page 12 Installation Guide | Advanced Active Filter AAF 007 Illustrations Illustrations CT_A CT_B DVC As CT_C AAF 007 RS-485+ RS-485- DVC As GND_O | Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283...
  • Page 13 Installation Guide | Advanced Active Filter AAF 007 Illustrations AC Drive CT_A CT_B CT_C AAF 007 CT_A Address No. 1 CT_B CT_C RS-485+ RS-485- AAF 007 GND_O CT_A CT_B Address No. 2 CT_C RS-485+ RS-485- AAF 007 + 7.5V GND_O CT_A Address No.
  • Page 14 Installation Guide | Advanced Active Filter AAF 007 Illustrations 35 A: ≥180 mm (7.1 in) 100 A: ≥ 230mm (9.0 in) 55 A: ≥180 mm (7.1 in) 150 A: ≥ 230mm (9.0 in) 35 A: ≥100 mm (3.9 in) 100 A: ≥150 mm (5.9 in) 55 A: ≥100 mm (3.9 in)
  • Page 15 Installation Guide | Advanced Active Filter AAF 007 Illustrations 35 A: ≥180 mm (7.1 in) 100 A: ≥ 230mm (9.0 in) 55 A: ≥180 mm (7.1 in) 150 A: ≥ 230mm (9.0 in) ≥100 mm (3.9 in) 35 A: ≥100 mm (3.9 in) 100 A: ≥150 mm (5.9 in)
  • Page 16 Installation Guide | Advanced Active Filter AAF 007 Illustrations 18.5 18.5 AAF02 61.0 482 (18.98) 10.0 (2.40) (0.39) 25.0 (0.98) 10.0 (0.39) | Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283...
  • Page 17 Installation Guide | Advanced Active Filter AAF 007 Illustrations CT_A CT_B CT_C Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283 |...
  • Page 18 Installation Guide | Advanced Active Filter AAF 007 Illustrations Filter Module 1 CT_A1 Filter Module 2 CT_A2 | Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283...
  • Page 19 Installation Guide | Advanced Active Filter AAF 007 Illustrations Filter Module 1 CT_A1 Filter Module 2 CT_A2 Filter Module 3 CT_A3 Grid Load CT_X AAF 007 Grid Load CT_A AAF 007 Grid Load CT_A AAF 007 Danfoss A/S © 2024.06...
  • Page 20 Title:Head of BU,Water Product Management Danfoss only vouches for the correctness of the English version of this declaration. In the event of the declaration being translated into any other language, the translator concerned shall be liable for the correctness of the translation...
  • Page 21 Title: Head of Customized Drives Danfoss only vouches for the correctness of the English version of this declaration. In the event of the declaration being translated into any other language, the translator concerned shall be liable for the correctness of the translation...
  • Page 22 Installation Guide | Advanced Active Filter AAF 007 Illustrations | Danfoss A/S © 2024.06 AN430846972679en-000202 / 130R1283...
  • Page 23  ...
  • Page 24 Danfoss reserves the right to alter its products without notice. This also applies to products ordered but not delivered provided that such alterations can be made without changes to form, fit or function of the product. All trademarks in this material are property of Danfoss A/S or Danfoss group companies.
