Specifications
PE M8 (15Nm)
90.7±1.0 mm [3.6±0.04 in]
9±1 mm [0.4±0.04 in]
Illustration 7.22 IP20 X6-V3 Internal Fan
X1 Mains 70mm (10Nm)
X2 Drive 70mm (10Nm)
Illustration 7.23 IP20 X6-V3 Internal Fan, Terminal Designation and 3D View
MG80C602
Design Guide
597.0±2.5 mm [15.9±0.10 in]
210.5±1.0 mm [8.3±0.04 in]
240.0±1.0 mm [9.4±0.04 in]
9±1 mm [0.4±0.04 in]
685.0±2.5 mm [27.0±0.10 in]
763.7±2.5 mm [30.1±0.10 in]
X3/X4 Capacitor disconnect 35mm (4Nm)
A/B Temperature 2.5mm (0.8Nm)
Danfoss A/S © 05/2019 All rights reserved.
370.0±1.0 mm [14.6±0.04 in]
418.0±2.5 mm [16.5±0.10 in]
210.5±1.0 mm [8.3±0.04 in]
12.0±1.0 mm [0.5±0.04 in]
8 holes must be used to fix the AHF
with M8 screws
