Specifications
500–690 V
50 Hz
Current Order
rating number
[A] [P/N]
15 130B5280
20 130B5281
24 130B5282
29 130B5283
36 130B5284
50 130B5285
58 130B5286
77 130B5287
87 130B5288
109 130B5289
128 130B5290
155 130B5291
197 130B5292
240 130B5293
296 130B5294
366 130B5295
395 130B5296
Table 7.18 AHF 010: 500–690 V, 50 Hz
MG80C602
Design Guide
AHF 010
Dimensions
Height Width
[mm (in)] [mm (in)]
592 (23.3) 378 (14.9)
592 (23.3) 378 (14.9)
593 (23.4) 378 (14.9)
621 (24.5) 378 (14.9)
621 (24.5) 378 (14.9)
736 (29) 418 (16.5)
736 (29) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
Danfoss A/S © 05/2019 All rights reserved.
Weight
Depth
[kg (lb)]
[mm (in)]
245 (9.6) 25 (55)
245 (9.6) 36 (79)
245 (9.6) 40 (88)
338 (13.3) 42 (93)
338 (13.3) 52 (115)
333 (13.3) 56 (123)
333 (13.3) 62 (137)
405 (15.9) 74 (163)
405 (15.9) 85 (187)
405 (15.9) 105 (231)
405 (15.9) 123 (271)
451 (17.8) 136 (300)
451 (17.8) 142 (313)
451 (17.8) 163 (359)
515 (20.3) 205 (452)
515 (20.3) 228 (503)
515 (20.3) 261 (575)
Enclosure
type
X3-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 ef
X4-V3 IP20 ef
X4-V3 IP20 ef
X5-V3 IP20 ef
X5-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X7-V3 IP20 ef
7
X7-V3 IP20 ef
X7-V3 IP20 ef
X8-V3 IP20 ef
X8-V3 IP20 ef
X8-V3 IP20 ef
