Component
CLIM iLOs
Blade element iLO
UPS (rack-mounted NS2100
commercial system only)
TCP/IP processes for OSM:
$ZTCP0
$ZTCP1

Ethernet Cables

Ethernet connections for a dedicated service LAN require CAT 5e or CAT 6 unshielded twisted-pair
(UTP) cables.

SWAN Concentrator Restrictions

NOTE: SWAN and SWAN 2 concentrators are only supported on the NS2100 commercial
system. SWAN/SWAN 2 concentrators can be connected to an IP CLIM or the 10/100 Ethernet
ports on a VIO enclosure with these restrictions:
Isolate any ServerNet wide area networks (SWANs) on the system. The system must be
equipped with at least two LANs: one LAN for SWAN/SWAN 2 concentrators and one for
the dedicated service LAN.
Most SWANs are configured redundantly using two or more subnets. Those subnets also
must be isolated from the dedicated service LAN.
Do not connect SWANs on a subnet containing a DHCP.

Dedicated Service LAN Links

You can implement up-system service LAN connectivity using:
"Dedicated Service LAN Links With Two VIO Enclosures" (page 99)
"Dedicated Service LAN Links With IP CLIMs" (page 100)
"Dedicated Service LAN Links With Telco CLIMs" (page 100)

Dedicated Service LAN Links With Two VIO Enclosures

You can implement up-system service LAN connectivity using the Ethernet ports on two VIO
enclosures. The values in this table show the identification for the Ethernet ports in slot 6B, port
Group.Module.Slot Default IP Address
CLIM at 100.2.4.2 192.168.36.52
CLIM at 100.2.4.3 192.168.36.53
CLIM at 100.2.4.4 192.168.36.54
Assigned by Dynamic
Host Configuration
Protocol (DHCP) server
on the NonStop system
console
N/A Assigned by DHCP
server on the dedicated
service LAN
N/A 192.168.36.31
192.168.36.32
N/A See "Dedicated Service
LAN Links" (page 99)
N/A See "Dedicated Service
LAN Links" (page 99)
Used By
The default DNS name is
SYSNAME-clim-name-iLO
Integrated Lights-Out Management
Processor (iLO MP)
For more information, see the HPE
Integrity iLO 2 MP Operations Guide.
The default DNS name is
SYSNAME-CPUnumber-iLO
OSM Service Connection
OSM Service Connection
OSM Notification Director
Dedicated Service LAN 99
