DL380 G6 Storage CLIM and SAS Disk Enclosure Configurations

"Two DL380 G6 Storage CLIMs, Two M8381-25 SAS Disk Enclosures" (page 77)
"Two DL380 G6 Storage CLIMs, Four M8381-25 SAS Disk Enclosures" (page 77)
"Four DL380 G6 Storage CLIMs, Four M8381-25 SAS Disk Enclosures" (page 78)

Two DL380 G6 Storage CLIMs, Two M8381-25 SAS Disk Enclosures

This illustration shows example cable connections for the two DL380 G6 Storage CLIM, two
M8381-25 SAS disk enclosure configuration.
Figure 21 Two DL380 G6 Storage CLIMs, Two M8381-25 SAS Disk Enclosure Configuration
This table lists the Storage CLIM, LUN, and bay identification for the factory-default system disk
locations in the configuration of two DL380 G6 Storage CLIMs and two M8381-25 SAS disk
enclosures. In this case, $SYSTEM, $DSMSCM, $AUDIT, and $OSS are configured as mirrored
SAS disk volumes:
Disk Volume Name
$SYSTEM
$DSMSCM
$AUDIT
1
$OSS
* For an illustration of the factory-default slot locations for a SAS disk enclosure, see
Locations for SAS Disk Devices" (page
1
If you have ordered $OSS, you need a 4 pair disk configuration
For an illustration of the factory-default slot locations for a SAS disk enclosure, see
Disk Volume Locations for SAS Disk Devices" (page

Two DL380 G6 Storage CLIMs, Four M8381-25 SAS Disk Enclosures

This illustration shows example cable connections for the two DL380 G6 Storage CLIM, four
M8381-25 SAS disk enclosures configuration. This configuration uses two SAS HBAs in slots 2
and 3 of each DL380 G6 Storage CLIM.
Primary and Mirror-Backup CLIM
100.2.3.1
100.2.3.1
100.2.3.1
100.2.3.1
76).
Backup and Mirror CLIM
100.2.3.3
100.2.3.3
100.2.3.3
100.2.3.3
"Factory-Default Disk Volume
76).
Storage CLIM Devices
"Factory-Default
