HPE Integrity NonStop NS2100 Planning Manual page 18

DL380 G6 Storage CLIM
The DL380 G6 Storage CLIM contains 4 PCIe HBA slots with these characteristics:
Storage CLIM
HBA Slot
1
2
3
4
The illustration below shows the Storage CLIM HBA slots. For more information about Storage
CLIMs, see "Storage CLIM Devices" (page
DL380p Gen8 Storage CLIM
The DL380p Gen8 Storage CLIM contains 3 PCIe HBA slots with these characteristics:
Storage CLIM
HBA Slot
1
2
3
18 NS2100 System Overview
Configuration
Part of base configuration
Part of base configuration
Optional customer order
Optional customer order
Configuration
Part of base configuration
SAS HBA is part of base
configuration
Optional customer order
Provides
ServerNet fabric connections via a PCIe 4x adapter.
One SAS external connector with two SAS links per connector and
6 Gbps per link is provided by the PCIe 8x slot
SAS or Fibre Channel
Fibre Channel
74).
Provides
ServerNet fabric connections via a PCIe 4x adapter.
Two 6 Gbps SAS ports.
NOTE: Fibre Channel HBA is not part of base configuration. An FC
HBA in slot 2 is an optional customer order.
SAS HBA with two 6 Gbps ports or FC HBA with two 8 Gbps ports.
NOTE: Not part of base configuration. Optional customer order.
