This illustration shows the Ethernet interfaces and ServerNet fabric connections on a DL380 G6
and DL380p Gen8 Telco CLIM. For illustrations of the front of this CLIM, see
(CLIMs)" (page
DL380 G6 Telco CLIM — Five Ethernet Copper Ports
Telco CLIM Slot
Slot 1
Slot 2
Slots 3, 4, 5
DL380p Gen8 Telco CLIM — Option 1 Five Ethernet Copper Ports
Telco CLIM Slot
Slot 1
Slot 2
Slots 3, 4, 5, 6
22 NS2100 System Overview
16).
Provides
ServerNet fabric connections via a PCIe 4x adapter
2-port 1GbE copper NIC
Not used
Provides
One ServerNet PCIe interface card, which provides the ServerNet fabric connections
2-port 1GbE copper NIC
Not used
"CLuster I/O Modules
