Cable Length Restrictions

Maximum allowable lengths of cables connecting the modular system components are:
Connection
Blade element to VIO
enclosure
(ServerNet-to-processor
port)
VIO enclosure to VIO
enclosure (cross-link
connection)
DL380 G6 Storage
CLIM to SAS disk
enclosure, copper
DL380p Gen8
Storage CLIM to
M8381-25, copper
SAS disk enclosure
Storage CLIM (FC
HBA interface) to
ESS
Storage CLIM (FC
HBA interface) to FC
tape
1
nnn indicates the length of the cable in meters. For example, M8900125 is 125 meters long; M8900-15 is 15 meters
long.
2
The M8381-25 SAS disk enclosure is also known as the D2700 SAS disk enclosure.
3
Hewlett Packard Enterprise has cable with maximum length 250 m.
104 Cables
104).
Fiber Connectors
Type
MMF LC-LC
MMF MTP-MTP
MMF SFF-8088 to
SFF-8088
MMF SFF-8088 to
SFF-8088
2
MMF LC-LC
OM2
MMF LC-LC
OM3
MMF LC-LC
OM2
MMF LC-LC
OM3
Maximum Length
125 m
50 m
6 m
6 (max length)
Transfer Maximum Length
Rate
3
2 Gbps 300 m
4 Gbps 150 m
8 Gbps 50 m
Transfer Maximum Length
Rate
2 Gbps 500 m
4 Gbps 380 m
8 Gbps 150 m
Transfer Maximum Length
Rate
3
2 Gbps 300 m
4 Gbps 150 m
8 Gbps 50 m
Transfer Maximum Length
Rate
2 Gbps 500 m
4 Gbps 380 m
8 Gbps 150 m
Product ID
1
M8900nnn
1
M8920nnn
1
M8906nnn
M8906-06
1
M8900nnn
Customer supplied
1
M8900nnn
Customer supplied
