SAS Disk Enclosure

The M8381-25 SAS disk enclosure is a rack-mounted disk enclosure that connects to the Storage
CLIM and supports up to 25 SAS disk drives or solid state drives (in any combination), and a
dual SAS domain from the Storage CLIMs to dual port SAS drives. The SAS disk enclosure
supports connections to SAS disk drives. Connections to FCDMs are not supported. You can
find more information about the M8381-25 SAS disk enclosure in the HPE StorageWorks
D2600/D2700 Disk Enclosure User Guide.
NOTE: Solid state drives are supported as of J06.13.
An M8381-25 SAS disk enclosure supports 6Gbps SAS protocol. It contains:
Twenty-five 2.5" dual-ported disk drive slots
Two power supplies
Two fans
Two independent I/O modules:
◦
SAS Domain A
◦
SAS Domain B
For illustrations of the SAS disk enclosure, see

Maintenance Switch

The HPE ProCurve maintenance switch provides the communication between the NS2100 system
through the VIO enclosures, CLIMs, the optional UPS, and the system console running HPE
NonStop Open System Management (OSM).
The NS2100 system requires multiple connections to the maintenance switch:
One connection from the ME ENET port on each of the two VIO enclosures
One connection from slot 6B, port A on each of the two VIO enclosures for the OSM Service
Connection and OSM Notification Director (optional if a dedicated service LAN is implemented
using CLIMs)
One connection to the iLO port on a CLIM
One connection to the iLO port on a blade element
One connection to an eth0 port on a CLIM
One connection to the optional UPS module
One connection to the system console running OSM

System Console

A system console is a Windows Server purchased from Hewlett Packard Enterprise that runs
maintenance and diagnostic software for NS2100 systems. When supplied with a new NS2100
system, system consoles have factory-installed Hewlett Packard Enterprise and third-party
software for managing the system. You can install software upgrades from the HPE NonStop
System Console Installer DVD.
Some system console hardware, including the Windows Server system unit, monitor, and
keyboard, can be mounted in the NS2100 system 19-inch rack. Other Windows Servers are
installed outside the rack and require separate provisions or furniture to hold the server hardware.
For more information on the system console, see
(page 101).
