HPE Integrity NonStop NS2100 Planning Manual page 30

NOTE: In OSM, if a blade element is not present or is powered off, processors might be
renumbered. For example, if processor 2 has been removed, processor 3 becomes processor
2 in OSM displays.
GMS Numbering Displayed in the OSM Service Connection:
Processor Group*
ID
0 400
1 401
2 402
3 403
*In OSM, the term Blade Complex is used for the group.
GMS Numbering Displayed in the OSM Low-Level Link:
Processor ID
0
1
2
3
*In OSM, the term Blade Complex is used for the group.
The form of the GMS numbering for a blade element displayed in the OSM Service Connection
is:
This illustration shows the physical GMS numbering for the rear view of a blade element:
30 NS2100 System Overview
Module
Blade Processor
Element
1 100
1 101
1 102
1 103
Group*
400
400
400
400
Slot
1, PCI adapter card.
(physical PCI slot 1)
3-4, power supplies.
(physical power supplies 1
and 2)
32—37, fans (physical fans
1 through 6)
Module
100
101
102
103
Port (Slot 2 only)
X
Y
Slot
1
1
1
1
