D Default Startup Characteristics and Naming Conventions

Each NS2100 system uses
default startup characteristics:
$SYSTEM disks residing in either SAS disk enclosures:
SAS and SAS CG Disk Enclosures
Systems with only two to three Storage CLIM/CLIM CGs and two SAS/SAS CG disk
enclosures with the disks in these locations:
Path
Primary
Backup
Mirror
Mirror-Backup
Configured system load paths
Enabled command interpreter input (CIIN) function
If the automatic system load is not successful, additional paths for loading are available in the
boot task. Using one load path, the system load task attempts to use another path and keeps
trying until all possible paths have been used or the system load is successful. These 16 paths
are available for loading and are listed in the order of their use by the system load task:
Load Path
1
2
3
4
5
6
7
8
9
10
11
12
13
14
108 Default Startup Characteristics and Naming Conventions
"Default Naming Conventions" (page 109)
CLIM/CLIM CG X1
Location
Group
100
100
100
100
Description Source Disk
Primary $SYSTEM-P
Primary $SYSTEM-P
Backup $SYSTEM-P
Backup $SYSTEM-P
Mirror $SYSTEM-M
Mirror $SYSTEM-M
Mirror backup $SYSTEM-M
Mirror backup $SYSTEM-M
Primary $SYSTEM-P
Primary $SYSTEM-P
Backup $SYSTEM-P
Backup $SYSTEM-P
Mirror $SYSTEM-M
Mirror $SYSTEM-M
Module Slot
2 3
2 3
2 3
2 3
Destination
Processor
0
0
0
0
0
0
0
0
1
1
1
1
1
1
and ships with the following
SAS/SAS CG Disk Enclosure
Enclosure Bay
1 1
1 2
2 3
2 4
ServerNet Fabric
X
Y
X
Y
X
Y
X
Y
X
Y
X
Y
X
Y
