Figure 22 Two DL380 G6 Storage CLIMs, Four M8381-25 SAS Disk Enclosure Configuration
This table lists the Storage CLIM, LUN, and bay identification for the factory-default system disk
locations in the configuration of two DL380 G6 Storage CLIMs and four M8381-25 SAS disk
enclosures. In this case, $SYSTEM, $DSMSCM, $AUDIT, and $OSS are configured as mirrored
SAS disk volumes:
Disk Primary
Volume CLIM
Name
$SYSTEM 100.2.3.1
$DSMSCM 100.2.3.1
$AUDIT 100.2.3.1
1
$OSS 100.2.3.1
1
If you have ordered $OSS, you need a 4 pair disk configuration
For an illustration of the factory-default slot locations for a SAS disk enclosure, see
Disk Volume Locations for SAS Disk Devices" (page

Four DL380 G6 Storage CLIMs, Four M8381-25 SAS Disk Enclosures

This illustration shows example cable connections for the four DL380 G6 Storage CLIM, four
M8381-25 SAS disk enclosures configuration. This configuration uses two SAS HBAs in slot 2
of each DL380 G6 Storage CLIM.
78 System Configuration Guidelines for NS2100 Systems
Backup Mirror Mirror-Backup
CLIM CLIM CLIM
100.2.3.3 100.2.3.3 100.2.3.1
100.2.3.3 100.2.3.3 100.2.3.1
100.2.3.3 100.2.3.3 100.2.3.1
100.2.3.3 100.2.3.3 100.2.3.1
Primary Mirror Primary
LUN LUN Disk Bay in
Primary
SAS
Enclosure
101 201 1
102 202 2
103 203 3
104 204 4
76).
Mirror Disk
Location in Mirror
SAS Enclosure
1
2
3
4
"Factory-Default
