The command interpreter input file (CIIN) is automatically invoked after the first processor is
loaded. The CIIN file shipped with new systems contains the TACL RELOAD * command, which
loads the remaining processors.
For default configurations of the HBA SAS ports, SAS disk enclosures, and load disks, see
"Configurations for Storage CLIMs and SAS Disk Enclosures" (page

Default Naming Conventions

An NS2100 system implements default naming conventions in the same manner as other Integrity
NonStop NS-series systems.
With a few exceptions, default naming conventions are not necessary for the modular resources
that make up an NS2100 system. In most cases, users can name their resources at will and use
the appropriate management applications and tools to find the location of the resource.
However, default naming conventions for certain resources simplify creation of the initial
configuration files and automatic generation of the names of the modular resources.
Preconfigured default resource names are:
Type of Object
ESS disk drive
SAS disk enclosure/SAS
CG disk enclosure
Modular tape drive
IP CLIM
Telco CLIM
Storage CLIM
Ethernet
Ethernet LIF
TCP/IP process
Telserv process
Description
Mirror backup
Mirror backup
Naming Convention
2
$ESS number
$SASnumber
$TAPE number
N group module slot
port
O group module slot
port
S group module slot
port
G group module slot
L group module slot port
$ZTC number
$ZTN number
Source Disk Destination
Processor
$SYSTEM-M 1
$SYSTEM-M 1
1
Example
$ESS20
$SAS20
$TAPE01
N100241
O100243
S100233
G10027
L10027B
$ZTC0
$ZTN0
ServerNet Fabric
X
Y
76).
Description
Twentieth ESS disk drive in
the system
Twentieth SAS disk volume
in the system
First modular tape drive in
the system
IP CLIM which has the X1
attachment point to the VIO
enclosure located in group
100, module 2, slot 4, port
1
Telco CLIM which has the
X1 attachment point to the
VIO enclosure located in
group 100, module 2, slot 4,
port 3
Storage CLIM which has the
X1 attachment point to the
VIO enclosure located in
group 100, module 2, slot 3,
port 3
Ethernet connection in
location 100.2.7
LIF for PIF at location
100.2.7.0.B
First TCP6SAM or TCP/IP
process for the system
First Telserv process for the
system
