HPE Integrity NonStop NS2100 Planning Manual page 61

Power and current specifications for each type of enclosure are:
Enclosure Type AC Power Lines
per Enclosure
Blade element 2
VIO enclosure 2
DL380 G6 Storage
CLIM 2
DL380p Gen8 Storage
CLIM 2
DL380 G6 IP or Telco
CLIM 2
DL380p Gen8
Networking CLIM 5
copper ports (IP or
Telco) 2
DL380p Gen8
Networking CLIM 3
copper/2 optical ports
(IP or Telco) 2
M8381-25 SAS disk
enclosure (no disks) 2
SAS disk drive 10k
rpm NA
SAS disk drive 15k
rpm NA
Solid state drive, 200
GB NA
Rack-mounted system 1
console (NSCR210 or
NSCR212)
Rack-mounted 1
keyboard and monitor
Maintenance switch 1
2
(Ethernet)
1
One of the plugs for an enclosure must be connected to one of the left-side extension bars and the other one connected
to one of the right-side extension bars. PDUs must be supplied from separate branch circuits.
2
Maintenance switch has only one plug. If a UPS is installed in the modular cabinet, the maintenance switch plug must
be connected to the extension bars on the right side of the modular cabinet.
Typical Power
1
Consumption
(Watts)
275 (8 GB)
292 (16 GB)
304 (32 GB)
262
135
123
130
117
123
75
5
4
5.7
105
28
20
Maximum Peak Inrush Current
Power (amps)
Consumption
(Watts)
469 (8 GB) NA
486 (16 GB)
501 (32 GB)
326 30
225 -
205 -
200 -
203 -
210 -
125 5
9 NA
7 NA
1.5 A (5 volts)
1.0 A (12 volts)
5.84
115
28 2
20 4
AC Input Power for Modular Cabinets 61
