Operating Temperature, Humidity, And Altitude - HPE Integrity NonStop NS2100 Planning Manual

Enclosure Type
DL380p Gen8
Networking CLIM, 5
copper ports (IP or
Telco)
DL380p Gen8
Networking CLIM, 3
copper ports/2 optical
ports (IP or Telco)
M8381-25 SAS disk
enclosure (no disks)
SAS 2.5 in. 10k rpm
disk drive
SAS 2.5 in. 15k rpm
disk drive
Solid state drive, 200
GB
Maintenance switch
1
(Ethernet)
Rack-mount system
console (NSCR210 or
NSCR212)
Rack-mount keyboard
and display
1
Maintenance switch has only one plug. If a UPS is installed in the modular cabinet, the maintenance switch plug must
be connected to the extension bars on the right side of the modular cabinet.

Operating Temperature, Humidity, and Altitude

Specification
Temperature (rack-mounted
system console and
maintenance switch)
Temperature (CLIMs, SAS
disk enclosure, blade
elements)
Humidity
2
Altitude
1
Operating and recommended ranges refer to the ambient air temperature and humidity measured 19.7 in. (50 cm)
from the front of the air intake cooling vents.
2
For each 1000 feet (305 m) increase in altitude above 10,000 feet (up to a maximum of 15,000 feet), subtract 1.5× F
(0.83× C) from the upper limit of the operating and recommended temperature ranges.
70 System Installation Specifications for NS2100 Systems
Number Installed Unit Heat
(BTU/hour) Typical
399
419
256
17
14
19.45
68
358
96
1
Operating Range
50° to 95° F (10° to 35° C)
50° to 95° F (10° to 35° C)
20% to 80%,
noncondensing
0 to 10,000 feet (0 to 3,000
meters)
Unit Heat
(BTU/hour)
Maximum
692
716
427
30
24
19.93
68
392
96
1
Recommended Range
68° to 77° F (20° to 25° C)
-
40% to 50%,
noncondensing
-
Total (BTU/hour)
Maximum Rate of Change
per Hour
18° F (10° C) Repetitive
36° F (20° C) Nonrepetitive
1.8° F (1° C) Repetitive
5.4° F (3° C) Nonrepetitive
6%, noncondensing
-
