UPS (Optional)

An uninterruptible power supply (UPS) is optional but recommended where a site UPS is not
available.
A UPS can be combined with an extended runtime module (ERM) to extend battery run time.
See "ERM (Optional with UPS)" (page
Depending on your power configuration, Hewlett Packard Enterprise supports these options:
"UPS for a Single-Phase Power Configuration (Optional)" (page 25)
"UPS for a Three-Phase Power Configuration (Optional)" (page 25)
WARNING!
tipping and stability issues. For more information, see the UPS user guide.

UPS for a Single-Phase Power Configuration (Optional)

Hewlett Packard Enterprise supports the HPE model R5000 UPS for the single-phase power
configuration because it utilizes the power fail support provided by OSM for this configuration.
For information about the requirements for installing a UPS, see
(UPS)" (page
There are two different versions of the R5000 single phase UPS:
For North America and Japan, the HPE AF460A is utilized and uses a NEMA L6-30P (30A)
input connector with 200 to 208V single-phase.
For International, the HPE AF461A is utilized and uses an IEC-60309 (32A) input connector
with 220V to 240V AC single-phase power.
NOTE: The AC input power cord for the single-phase UPS is routed to exit the modular cabinet
at either the top or bottom rear corners of the cabinet, depending on what is ordered for the site
power feed (the large output receptacle is unused).
For the UPS power and environmental requirements, see
NS2100 Systems" (page
instructions, see the HPE UPS R5000 User Guide and the HPE UPS Network Module User Guide
at http://www.hpe.com/support/UPS_3_Phase_Manuals
For other UPSs, see the documentation shipped with the UPS.

UPS for a Three-Phase Power Configuration (Optional)

Hewlett Packard Enterprise supports the HPE model R12000/3 UPS for the three-phase power
configuration because it utilizes the power fail support provided by OSM for this configuration.
For information about the requirements for installing a UPS, see
(UPS)" (page
There are two different versions of the R12000/3 UPS:
For North America and Japan, the HPE AF429A is utilized and uses an IEC309 560P9 (60A)
input connector with 208V three-phase Wye.
For International, the HPE AF430A is utilized and uses an IEC309 532P6 (32A) input
connector with 400V three-phase Wye.
NOTE: The R12000/3 UPS has two output connectors.
For the R12000/3 UPS power and environmental requirements, see
planning, installation, and emergency power-off (EPO) instructions, see the HPE 3 Phase UPS
User Guide. This guide is on the Hewlett Packard Enterprise website at:
http://www.hpe.com/support/UPS_3_Phase_Manuals
UPSs and ERMs must be mounted in the lowest portion of the system to avoid
40).
44). For planning, installation, and emergency power-off (EPO)
40).
26).
"System Installation Specifications for
"Uninterruptible Power Supply
"Uninterruptible Power Supply
Chapter 3 (page 44). For
NS2100 Hardware 25
