The X fabric connects to ports BX and AX. The Y fabric connects to ports BY and AY.

VIO Enclosure Group-Module-Slot Numbering

An NS2100 system supports a single pair of VIO enclosures, identified as group 100. For an
illustration of the VIO enclosure slots, see
VIO Enclosure (AC-Powered)
Group
100
Module Slot
X Y Displayed by
Fabric Fabric OSM
2 3 1
2
3
4
5
6
6
7
7
7
14
15, 18
16, 17
Figure 3 (page 32).
Item
Displayed on
Chassis
1 Not supported
2 Not supported
3 Storage CLIM
4 IP CLIM
Telco CLIM
5 Not supported
6a Ethernet ports
(optical)
1
6b Ethernet ports
(copper)
7a Ethernet ports
(optical)
7b Ethernet ports
(copper)
7c Not supported
14.1 - 14.4 Processor ports
(processors 0-3)
15, 18 Power supplies
16, 17 Fans
Component Location and Identification in an NS2100 System
Ports
-
-
1 and 3 for 2 Storage
CLIMs; 1 - 4 for 4 Storage
CLIMs
1 - 2
1 - 2
-
C and D (10/100/1000
Mbps)
A , B (10/100 Mbps)
C, D (10/100/1000 Mbps)
C, D (10/100/1000 Mbps)
A , B (10/100 Mbps)
C, D (10/100/1000 Mbps)
-
1 - 4
-
-
