A of both VIO enclosure modules (module 2 and module 3) and connected to the maintenance
switch:
GMS for Ethernet
Port Location in VIO
Enclosure
100.2.6b Port A
100.3.6b Port A

Dedicated Service LAN Links With IP CLIMs

You can implement up-system service LAN connectivity using IP CLIMs, if the system has at
least two IP CLIMs. The values in this table show the identification for the IP CLIMs in an NS2100
system and connected to the maintenance switch. For example, in this table an IP CLIM named
N100241 is connected to slot 4, port 1 of the VIO enclosure located in group 100, module 2.
GMS for IP CLIM Location in VIO
Enclosure
100.2.4.1
100.3.4.1

Dedicated Service LAN Links With Telco CLIMs

You can implement up-system service LAN connectivity using Telco CLIMs, if the system has
at least two Telco CLIMs. The values in this table show the identification for the Telco CLIMs in
an NS2100 system and connected to the maintenance switch. For example, in this table a Telco
CLIM named O100241 is connected to slot 4, port 1 of the VIO enclosure located in group 100,
module 2.
GMS for Telco CLIM Location in
VIO Enclosure
100.2.4.1
100.3.4.1
100 Maintenance and Support Connectivity
Ethernet PIF Ethernet LIF
G10026.0.A L1002R
G10036.0.A L1003R
TCP/IP Stack
$ZTCP0
$ZTCP1
TCP/IP Stack
$ZTCP0
$ZTCP1
TCP/IP Stack IP Configuration
$ZTCP0 IP: 192.168.36.10
Subnet: %FFFF0000
Hostname: osmlanx
$ZTCP1 IP: 192.168.36.11G
Subnet: %FFFF0000
Hostname: osmlany
IP Configuration
IP: 192.168.36.10
Subnet:
%hFFFFFF00
Hostname: osmlanx
IP: 192.168.36.11
Subnet:
%hFFFFFF00
Hostname: osmlany
IP Configuration
IP: 192.168.36.10
Subnet:
%hFFFFFF00
Hostname: osmlanx
IP: 192.168.36.11
Subnet:
%hFFFFFF00
Hostname: osmlany
