Modular cabinet weight includes the PDUs and their associated wiring and receptacles.
2
Maximum payload weight for the 36U G2 rack cabinet: 1200 lbs (544.3 kg).
3
Maximum payload weight for the 42U G2 rack cabinet: 1200 lbs (544.3 kg).
4
Maximum payload weight for the 36U Intelligent rack cabinet: 3000 lbs (1360 kg).
5
Maximum payload weight for the 42U Intelligent rack cabinet: 3000 lbs (1360 kg).
6
iPDU=Intelligent PDU
7
mPDU=Modular PDU
For examples of calculating the weight for various enclosure combinations, see
Specifications for Enclosure Combinations" (page

Modular Cabinet Stability

Cabinet stabilizers are required when you have less than four cabinets bayed together.
NOTE: Cabinet stability is of special concern when equipment is routinely installed, removed,
or accessed within the cabinet. Stability is addressed through the use of leveling feet, baying
kits, fixed stabilizers, and/or ballast.
For information about the Intelligent rack, your Hewlett Packard Enterprise service provider can
consult the HPE Intelligent Rack Family User Guide.
NOTE: For instructions on grounding the rack, ask your Hewlett Packard Enterprise service
provider to refer to the instructions in the HPE Intelligent Rack Family Options Installation Guide.

Environmental Specifications

This subsection provides information about environmental specifications and covers these topics:
"Heat Dissipation Specifications and Worksheet" (page 69)
"Operating Temperature, Humidity, and Altitude" (page 70)
"Nonoperating Temperature, Humidity, and Altitude" (page 71)
"Cooling Airflow Direction" (page 71)
"Typical Acoustic Noise Emissions" (page 71)
"Tested Electrostatic Immunity" (page 71)

Heat Dissipation Specifications and Worksheet

Enclosure Type
8 GB Blade element
16 GB Blade element
32 GB Blade element
VIO enclosure
DL380 G6 Storage
CLIM
DL380 G6 IP or Telco
CLIM
DL380p Gen8
Storage CLIM
Number Installed Unit Heat
(BTU/hour) Typical
938
996
1037
894
461
444
419
71).
Unit Heat
(BTU/hour)
Maximum
1600
1658
1710
1112
768
682
699
Modular Cabinet Stability
"Calculating
Total (BTU/hour)
69
