HPE Integrity NonStop NS2100 Planning Manual page 68

Enclosure Type
36U Intelligent rack
4
42U Intelligent rack
5
6
iPDU core
iPDU extension bar
7
mPDU core
mPDU extension
bar
Blade element
(rx2800 i2)
VIO enclosure
DL380 G6 CLIM
DL380p Gen8
CLIM
M8381-25 SAS
disk enclosure (no
disks)
SAS disk drive
Solid state drive
CLIM patch panel
Maintenance
switch (Ethernet)
rack-mount system
console, keyboard,
and display
R5000 UPS
(single-phase)
R5500 XR UPS
(single-phase)
R12000/3 UPS
(three-phase)
ERM for
three-phase power
(AF434A)
R5000 ERM for
single-phase power
R5500 ERM for
single-phase power
Total
68 System Installation Specifications for NS2100 Systems
Number of Weight
Enclosures
lbs
318
333
20
2.5
12
1.5
52
62
58
55
38
1
1
5
5
38
126
160
307 (with
batteries)
135 (without
batteries)
170
139
167
--
Total
kg lbs
144
151
9.1
1.1
5.5
0.7
23.6
28.2
26
24
17
0.5
0.5
2.3
2.3
12.7
57
73
139.2 (with
batteries)
59.8 (without
batteries)
77
63
75
--
kg
