CLIM Connection Group-Module-Slot-Port Numbering

This table lists the default numbering for VIO connections to a CLIM:
CLIM Group
100
100
The illustration below shows the slot and connector locations from the VIO modules to two DL380
G6 Storage CLIMs.
Figure 4 DL380 G6 Storage CLIM Connections to VIO Enclosures
Module
2
3
Component Location and Identification in an NS2100 System
VIO Slot
3 (Storage CLIM)
4 (IP CLIM)
4 (Telco CLIM)
3 (Storage CLIM)
4 (IP CLIM)
4 (Telco CLIM)
PIC Port Numbers
1 and 3 for 2 Storage CLIMs,
1 - 4 for 4 Storage CLIMs
1-2
1 and 3 for 2 Storage CLIMs,
1 - 4 for 4 Storage CLIMs
1-2
