IP Addresses

NS2100 systems require Internet protocol (IP) addresses for these components that are connected
to the dedicated service LAN:
VIO enclosure logic boards
Maintenance switches
System consoles
CLIM maintenance interfaces (eth0)
CLIM iLOs
Blade iLOs
UPSs (optional)
Intelligent PDUs (iPDUs)
These components have default IP addresses that are preconfigured at the factory. You can
change these preconfigured IP addresses to addresses appropriate for the LAN environment:
Component
VIO enclosure
Maintenance switch
(rack-mounted)
Maintenance switch (ProCurve)
(Additional switches)
Maintenance switch (ProCurve)
(More than 10 switches)
iPDU in rack 1, front mounting
rail
iPDU in rack 1, rear mounting
rail
iPDU in rack 2, front mounting
rail
iPDU in rack 2, rear mounting
rail
iPDU in rack 3, front mounting
rail
iPDU in rack 3, rear mounting
rail
Primary system console
(rack-mounted or stand-alone)
Backup system console
(rack-mounted only)
Up to two additional system
consoles (rack-mounted only)
CLIM Maintenance Interfaces
(eth0)
98 Maintenance and Support Connectivity
Group.Module.Slot Default IP Address
100.2 192.168.36.202
100.3 192.168.36.203
N/A 192.168.36.21
N/A 192.168.36.22 -
192.168.36.30
N/A 192.168.36.12 -
192.168.36.20
N/A 192.168.42.11
N/A 192.168.42.12
N/A 192.168.42.21
N/A 192.168.42.22
N/A 192.168.42.31
N/A 192.168.42.32
N/A 192.168.36.1
N/A 192.168.36.2
N/A 192.168.36.5
192.168.36.6
CLIM at 100.2.3.1 192.168.36.41
CLIM at 100.2.3.2 192.168.36.42
CLIM at 100.2.3.3 192.168.36.43
CLIM at 100.2.3.4 192.168.36.44
CLIM at 100.2.4.1 192.168.36.51
Used By
OSM Low-Level Link
OSM Service Connection
OSM Low-Level Link
OSM Service Connection
OSM Notification Director
OSM Service Connection
