1 NS2100 System Overview

The characteristics of an NS2100 system are:
Processor
Input Power
Cabinet
Main memory
Supported processor configurations
Maximum processors
Supported CLuster I/O Modules (CLIMs)
Maximum CLIMs
Minimum CLIMs
Maximum SAS disk enclosures per Storage CLIM pair
Maximum SAS disk drives per Storage CLIM pair
Maximum VIO enclosures
Maximum embedded Ethernet connectivity per VIO
enclosure
Maximum expanded Ethernet connectivity per VIO
enclosure (optional)
Enterprise Storage System (ESS) support available
through Storage CLIM
M8201R Fibre Channel to SCSI router support
I/O Adapter Module (IOAM) enclosures
Fibre Channel disk modules (FCDMs)
Connection to NonStop ServerNet Clusters
Connection to NonStop S-series I/O
1
For information about coexistence limits for IP and Telco CLIMs, see
Figure 1 (page 14)
modular cabinet with the optional extended runtime module (ERM) and UPS for the three-phase
power configuration.
1
shows the rear view of an NS2100 system with four blade elements in a 42U
Intel Itanium
AC-powered with single-phase and three-phase power
configurations
42U and 36U, 19 inch rack
8 GB, 16 GB, or 32 GB
2 or 4
4
Storage CLIMs
IP CLIMs for Ethernet
Telco CLIMs for Ethernet (M3UA protocol)
Up to 6 CLIMs using these possible combinations:
Up to 4 Storage CLIMs (two pairs)
Up to 2 IP CLIMs if there are 0 Telco CLIMs
Up to 2 Telco CLIMs if there are 0 IP CLIMs
0 IP CLIMs
0 Telco CLIMs
2 Storage CLIMs
A Storage CLIM pair supports a maximum of 4 SAS disk
enclosures. This maximum applies to G6 and Gen8
Storage CLIM types.
100
2 required (one each for X and Y fabrics)
4 embedded Ethernet ports (one port is reserved for OSM)
4 optional expanded Ethernet ports (copper/optical)
Supported
Not supported
Not supported
Not supported
Not supported
Not supported
IP and Telco CLIM Coexistence Limits (page 88).
