Displaying LACP Port Counters

You can display statistics for LACP protocol messages.
Parameter
LACPDUs Sent
LACPDUs Received
Marker Sent
Marker Received
Marker Unknown Pkts
Marker Illegal Pkts
Web – Click Port, LACP, Port Counters Information. Select a member port to display
the corresponding information.
CLI – The following example displays LACP counters for port channel 1.
Console#show lacp 1 counters
Port channel: 1
-------------------------------------------------------------------------
Eth 1/ 2
-------------------------------------------------------------------------
LACPDUs Sent:
LACPDUs Receive:
Marker Sent:
Marker Receive:
LACPDUs Unknown Pkts: 0
LACPDUs Illegal Pkts: 0
. .
.

Table 8-1 LACP Port Counters

Description
Number of valid LACPDUs transmitted from this channel group.
Number of valid LACPDUs received by this channel group.
Number of valid Marker PDUs transmitted from this channel group.
Number of valid Marker PDUs received by this channel group.
Number of frames received that either (1) Carry the Slow Protocols Ethernet
Type value, but contain an unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the Slow Protocols Ethernet
Type.
Number of frames that carry the Slow Protocols Ethernet Type value, but contain
a badly formed PDU or an illegal value of Protocol Subtype.

Figure 8-6 LACP - Port Counters Information

19
10
0
0
Creating Trunk Groups
8
28-7
8-13
