Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide

Administration - Phonebook

Field
Phonebook Configuration - Disabled
Disabled
Phonebook Configuration - Imported CSV file
Imported CSV file
Import
Encoding
Number fields
Phonebook Configuration - LDAP
LDAP
URI
Bind user (Optional)
Bind password (Optional)
Base (Optional)
14215700-IG, Edition 8.0
April 2018, Original document
Setting
As default, phone book configuration is disabled.
You can configure the server to retrieve phone book data using
LDAP server or by import of phone book data from a CSV file.
Enable this if you want to import phone book data from CSV
file.
Browse for the CSV file to import.
Note: The CSV file must contain correct format. For more
information, see "Parameter Overview" on
Select the correct encoding for the CSV file. You can choose
between UTF-8, ISO/IEC 8859-1 or Windows-1252.
Note: The encoding depends on the software that was used to
generate the CSV file. If you use Microsoft Windows, you will
probably select Windows-1252.
Enter the indexes of the columns containing dialable numbers.
Enable this if you want to configure the server to retrieve phone
book data using LDAP server.
For an example of LDAP configuation, see
view" on page 223.
Enter the URI of the LDAP server.
E.g. ldap://example.com
Enter the username used for authentication against LDAP.
Note: It might be necessary to specify the path for username
(DOMAIN\username).
E.g. CN=Manager, DC=example, DC=com.
Enter the Bind user's password.
Enter the base path where the users are located in the LDAP
structure.
E.g. DC=example, DC=com.
page 223.
"Parameter Over-
259
