SpectraLink IP-DECT 200 Installation Manual
Hide thumbs
Also See for IP-DECT 200:
- Installation and configuration manual (456 pages) ,
- Configuration manual (49 pages) ,
- Interoperability manual (31 pages)
Related Manuals for SpectraLink IP-DECT 200
Summary of Contents for SpectraLink IP-DECT 200
- Page 1 Spectralink IP-DECT Server 200 Deployment and Installation Guide 14212650-IG, Edition 1.0 April 2018, Original document...
-
Page 2: Installing Multiple Spectralink Ip-Dect Server 200S In Large Areas
The drawings and specifications contained herein are the property of Spectralink and shall be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith. -
Page 3: Table Of Contents
Wall-Mount and Power on the Spectralink IP-DECT Server Different Installation Use Cases Installing a Single Spectralink IP-DECT Server 200 in a Small Area Installing Multiple Spectralink IP-DECT Server 200 in a Small Area Installing Single Spectralink IP-DECT Server 200s in Large Areas... -
Page 4: About This Guide
About This Guide This guide describes how to deploy and install a Spectralink IP-DECT Server 200. It does not describe the configuration of the Spectralink IP-DECT Server 200. Configuration of the Spectralink IP-DECT Server can be done using the following 3 methods:... -
Page 5: Related Documentation
Available online at http://support.spectralink.com/products. Spectralink DECT Training mater- In order to gain access to the Spectralink training mater- ial, you must attend training and become Spectralink Cer- tified Specialist. Please visit http://- partneraccess.spectralink.com/training/classroom-train-... -
Page 6: Description - Spectralink Ip-Dect Server 200
Description - Spectralink IP-DECT Server 200 The Spectralink IP-DECT Server 200 is a single cell system (one built-in base station in the server) supporting SIP lines only. The Spectralink IP-DECT Server 200 is designed with connector for External Antenna. Up to 3 additional Spectralink DECT Repeaters can be added to the Spectralink IP-DECT Server 200. -
Page 7: Spectralink Ip-Dect Server 200 Appearance And Components
Spectralink IP-DECT Server 200 Deployment and Installation Guide Spectralink IP-DECT Server 200 Appearance and Com- ponents Below you will find a description of the Spectralink IP-DECT Server 200 appearance and com- ponents: Spectralink IP-DECT Server 200 - bottom Spectralink IP-DECT Server 200 - rear... -
Page 8: Spectralink Ip-Dect Server 200 Reset Button
Spectralink IP-DECT Server 200 - front Spectralink IP-DECT Server 200 Reset Button You can restart or reset the Spectralink IP-DECT Server 200 by pressing the Reset button on the bottom of face plate of the server. The following table contains a description of the different actions that take place when pressing the Reset button. -
Page 9: Spectralink Ip-Dect Server 200 Led Indicators
Spectralink IP-DECT Server 200 Deployment and Installation Guide Spectralink IP-DECT Server 200 LED Indicators Below you will find information about LED indicators on the server. Front Cover The server front cover has one indicator describing the server faults and failures. The indicator is off when the server is not powered. -
Page 10: When Ordering Handsets And Spectralink Ip-Dect Server 200
If you want to allow more users to use the system, you can allocate up to 12 handsets per Spectralink IP-DECT Server 200 (up to any 6 handsets can be used at the same time). 2. Determine which handsets will be associated with each new (or existing) Spectralink IP- DECT Server 200 on your virtual PBX. -
Page 11: Prepare Your Handsets And Spectralink Ip-Dect Server 200 For Installation
1. Charge the battery in the handsets so the handsets can be subscribed and tested. For more information, see Handset User Guides. 2. Turn on the Spectralink IP-DECT Server 200(s) and verify the power LED is light is on. For more information, see "Power Requirements for the Spectralink IP-DECT Server 200"... -
Page 12: Find The Best Installation Locations
Depending on the type of product bundle ordered - the AC power supply for the IP-DECT Server 200 may be included. 3. Verify with the end users where coverage is needed so the Spectralink IP-DECT Server 200 can be placed near center of the 75 meters/245-feet radius where users are normally situated. -
Page 13: Wall-Mount And Power On The Spectralink Ip-Dect Server 200
Wall-Mount and Power on the Spectralink IP-DECT Server 200 For best RF coverage, the Spectralink IP-DECT Server 200 must be mounted vertically on walls. 1. Mount the Spectralink IP-DECT Server 200 on the wall using the anchors and screws accom- panying the product. Note: When you place the Spectralink IP-DECT Server 200 on the screws, ensure that the screws do not touch the printed circuit board. - Page 14 Spectralink IP-DECT Server 200 Deployment and Installation Guide 3. After installing the Spectralink IP-DECT Server 200 you need to power it up. 14212650-IG, Edition 1.0 April 2018, Original document...
-
Page 15: Different Installation Use Cases
Server 200 within a 30 meter/100-feet radius cell that contains the users and the areas where they are situated. 2. If the coverage area has multiple floors or goes across heavy walls, the Spectralink IP-DECT Server 200’s range may be limited to ~15 meter/~50 feet or less for the floor above or across the heavy walls. -
Page 16: Installing Multiple Spectralink Ip-Dect Server 200 In A Small Area
200s within a 30 meters/100-feet radius. Users can talk within their own 30 meters/100-feet cell. 1. Follow the previous instructions and select the optimal locations for up to 5 Spectralink IP- DECT Server 200s serving up to 30 handset users and the areas where they are situated. -
Page 17: Installing Single Spectralink Ip-Dect Server 200S In Large Areas
Large areas defined as: each area with a radius larger than 30 meters/100 feet; 30 meters/100-feet cells do not overlap. The image below shows 2 independent cells over 30 meters/100 feet apart with 1 Spectralink IP- DECT Server 200 in each. -
Page 18: Installing Multiple Spectralink Ip-Dect Server 200S In Large Areas
Large areas defined as: each area with a radius larger than 30 meters/100 feet; 30 meters/100-feet cells do not overlap. The image below shows 2 independent cells over 30 meters/100 feet. apart with 1 Spectralink IP- DECT Server 200 in each. - Page 19 Spectralink IP-DECT Server 200 Deployment and Installation Guide Installing Multiple Spectralink IP-DECT Server 200s in Large Areas (2) Large areas defined as: radius larger than 30 meters/100 feet; 30 meters/100-feet cells overlap. The image below shows overlapping cells supporting up to 5 base units (total).
-
Page 20: Product Compatibility
If you have any questions about product compatibility, contact your system administrator. You can use the Spectralink IP-DECT Server 200 with other Spectralink products as identified by the type approval model ID and/or part number located on the label of the product. - Page 21 Spectralink IP-DECT Server 200 Deployment and Installation Guide Spectralink Server Licenses for 200 Lync/SfB + Security (TLS, SRTP) | IP-DECT 1407 5511 Server 200 Security (TLS, SRTP) | IP-DECT Server 200 1407 5281 14212650-IG, Edition 1.0 April 2018, Original document...
