Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
Field
Multicast signaling (Optional)
Multicast address (Optional)
Multicast TTL (Optional)
Default sync type (Optional)
LAN sync transport protocol
(Only visible if license loaded)
14215700-IG, Edition 8.0
April 2018, Original document
Multicast signaling is optimal when having many base
stations and is required with more than 256 base sta-
tions connected.
If enabled, this will impose multicast support for the net-
work.
For more information, see
page 126.
Multicast address used for signaling.
Default value: 239.255.1.11
Please refer to RFC2365 and RFC4291 for details.
The TTL is used to limit the propagation of the mul-
ticast packets across routers.
Default value: 1
Note:The TTL is configurable and it is possible to
change the value according to network topology. For
more information, see vendor specific documentation.
This setting controls the default sync type for new
base stations connecting to the server.
Possible values: Free running, Radio or LAN.
Note: Selecting Free running will configure each
base station as a sync master. For more information,
see also Synchronization and Deployment Guide.
Default value: Radio
The protocol transport layer used by PTP for LAN
sync.
Possible values: Ethernet, IPv4 or IPv6.
For more information about using LAN syn-
chronization, see "LAN Based Synchronization
(License Required)" on
"Using Multicast" on
page 131.
110
