BroadSoft Partner Configuration Guide
Spectralink IP-DECT Server Series
March 2019
Document Version 1.8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-DECT 200 and is the answer not in the manual?

Questions and answers

Related Manuals for SpectraLink IP-DECT 200

Summary of Contents for SpectraLink IP-DECT 200

  • Page 1 BroadSoft Partner Configuration Guide Spectralink IP-DECT Server Series March 2019 Document Version 1.8...
  • Page 2 Any product names mentioned in this document may be trademarks or registered trademarks of BroadSoft or their respective companies and are hereby acknowledged. This document is printed in the United States of America. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 ©...
  • Page 3 Edited and published document. Expanded document with the support of Device Management. Edited changes and published document. Updated document with Spectralink IP-DECT Server Series version PCS17A and 55735 validation with BroadWorks Release 22.0. Edited changes and published document. Updated document with Spectralink IP-DECT Server Series version PCS18B and 60232 validation with BroadWorks Release 22.0.

  • Page 4: Table Of Contents

    5.2.4 Configure BroadWorks User .................... 38 5.2.5 Customize Tags ........................ 38 5.2.6 Configure Spectralink IP DECT Server ................39 5.2.7 File Authentication Using MAC Address from Client Certificate ........40 BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC.
  • Page 5 Upgrade from Previous CPE Kits ..................... 43 Appendix A: Reference IP-DECT Server Configuration Files ..........44 References ............................49 BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 5 OF 49...
  • Page 6 Figure 12 MAC Address Definition for Device Profile Instance .............. 41 Figure 13 Device Profile Type Update for MAC-Based Authentication Using Client Certificate ..42 Figure 14 Authentication Mode Set to MAC-Based and Sourced from Client Certificate ....43 BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 ©...

  • Page 7: Overview

    Overview This guide describes the configuration procedures required for the Spectralink IP-DECT Server Series for interoperability with BroadWorks. This includes these models: Spectralink IP-DECT 200  Spectralink IP-DECT 400  Spectralink IP-DECT 6500  The IP-DECT Server Series are access devices that use the Session Initiation Protocol (SIP) to communicate with BroadWorks for call control.

  • Page 8: Interoperability Status

    This section identifies interface capabilities that have been verified through testing as supported by Spectralink IP-DECT Server Series. The Supported column in the tables in this section identifies the Spectralink IP-DECT Server Series’ support for each of the items covered in the test plan, with the following...

  • Page 9: Sip Interface Capabilities

    Caveats and clarifications are identified in the Comments column. 2.2.1 SIP Interface Capabilities The Spectralink IP-DECT Server Series has completed interoperability testing with BroadWorks using the BroadWorks SIP Phone Interoperability Test Plan [5]. The results are summarized in the following table.
  • Page 10 Three-Way Calling Network-Based Conference DUT Services – Register Authentication Registration and Maximum Registration Authentication Minimum Registration Invite Authentication Re-Invite/Update Authentication Refer Authentication BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 10 OF 49...
  • Page 11 Do Not Disturb Ring Splash Key Synchronization, Shared Line Call Forwarding Call Forwarding Always Ring Splash Call Forwarding Always Diversion Inhibitor Security Classification BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 11 OF 49...
  • Page 12 Security Classification Classification Advanced Phone Network-Based Conference Creator Services – Network-Based Conference Conference Event Participant Meet-Me Conference Participant Redundancy DNS SRV Lookup BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 12 OF 49...
  • Page 13 Call to WebRTC Client Register Outgoing Invite Incoming Invite IPV6 Call Origination Call Termination Session Audit Ringback Codec Negotiation/Renegotiation Voice Message Deposit/Retrieval Call Control BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 13 OF 49...

  • Page 14: Other Interface Capabilities

    Redundancy Video Dual Stack with Alternate Connectivity 2.2.2 Other Interface Capabilities This section identifies whether the Spectralink IP-DECT Servers have implemented support for the following: BroadWorks Xtended Services Interface (Xsi)  Extensible Messaging and Presence Protocol (XMPP) (BroadCloud/BroadWorks  Collaborate Instant Messaging and Presence [IM&P]) Support for these interfaces is demonstrated by completing the BroadWorks SIP Phone Xsi and XMPP Test Plan [6].
  • Page 15 Record Mode set to On Demand Perform User Initiated Start with Record Mode set to On Demand Perform Mid-Call Start Recording BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 15 OF 49...

  • Page 16: Known Issues

    The issues identified are device deficiencies or bugs, and are typically not BroadWorks release dependent. The Issue Number is a tracking number for the issue. If it is a Spectralink issue, the issue number is from Spectralink’s tracking system. If it is a BroadWorks issue, the issue number is from BroadSoft’s tracking system.

  • Page 17: Broadworks Configuration

    This section identifies the device profile type settings to use when deploying the Spectralink IP-DECT Server Series with BroadWorks. Create a device profile type for the Spectralink IP-DECT Server Series with settings as shown in the following example. A separate device profile type should be created for each Spectralink IP-DECT Server model.

  • Page 18: Broadworks Configuration Steps

    Figure 1 Device Identity/Profile Type BroadWorks Configuration Steps No additional BroadWorks configuration steps are required. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 18 OF 49...

  • Page 19: Ip-Dect Server Configuration

    DECT Server configuration settings identified in this section have been derived and verified through interoperability testing with BroadWorks. For configuration details not covered in this section, see the Provisioning Guide Spectralink IP-DECT Servers and for the IP DECT Server. BroadSoft Device Management...

  • Page 20: Configure Sip Interface Settings

    Controller (SBC) if one is deployed between the IP DECT Server Series and BroadWorks. If there are redundant SBCs, set it to the FQDN for the SBC cluster. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC.

  • Page 21: Configure Service Settings

    Shared Call Appearance, Busy Lamp Field, Feature Key Synchronization, Call Center, Emergency Call, Advice of Charge, Call Recording, and Security Classification. 4.4.1 Shared Call Appearance Configuration Not Supported. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 21 OF 49...

  • Page 22: Busy Lamp Field Configuration

    Not Supported. 4.4.9 Conference Event Configuration Not Supported. Xtended Services Interface (Xsi) Feature Configuration Not Supported. Instant Message and Presence Configuration Not Supported. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 22 OF 49...

  • Page 23: Device Management

    Management interface between the device and BroadWorks with the intent to ensure interoperability. The Supported column in the following table identifies the Spectralink IP-DECT Server Series’ support for each of the items covered in the test plan packages, with the following...

  • Page 24: Device Management Configuration

    No Touch Provision via Vendor redirect Device Management Configuration This section identifies the steps required to enable the Spectralink IP-DECT Server Series for device management. For Device Management configuration details not covered here, see the BroadWorks Device Management Configuration Guide and the BroadWorks [8].

  • Page 25: Configure Broadworks Tags

    Create System Default Tags Browse to System → Resources → Device Management Tag Sets and select the System Default tag set. The Spectralink configuration templates make use of the tags in the following table. Add the tags if they do not already exist.
  • Page 26 Configure the tag set name using the device name appended by Tags: Spectralink-IP-DECT tags. Add the device type-specific tags in the following table to the device tag set. If the tag set already exists, make sure that at least the tags marked as required are defined.
  • Page 27 The Spectralink IP-DECT Server or DECT Server checks for a version file and a binary file. They must be located as /.bin.ver and /.bin BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 27 OF 49...
  • Page 28 Otherwise they will have to be manually activated %IP-DECT-SECURITY- true/false If enabled new base stations will ALLOW-NEW-RFP% be allowed to connect to the BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 28 OF 49...
  • Page 29 Community name SNMP community name. COMMUNITY% %IP-DECT-SNMP- enabled/disabled Enable/disable SNMP. ENABLE% %IP-DECT-SNMP- text SNMP contact information. SYSCONTACT% %IP-DECT-SNMP- text SNMP location information. SYSLOCATION% BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 29 OF 49...

  • Page 30: Configure Broadworks Device Profile Type

    Group administrators use the device profile type to create a device profile. The device profile is an instance of the device profile type that is associated with a physical device. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 ©...
  • Page 31 Configuration Method 1: Import This section identifies the steps necessary to make use of the Device Management import feature to configure BroadWorks to add the Spectralink IP DECT Server as a Device Management-enabled device type. Also, see the BroadWorks CPE Kit Usage Guide [8].

  • Page 32: Figure 4 Device Access Fqdn

    Click the Files and Authentication link and then select the option to rebuild all the system files. Firmware files must be obtained from Spectralink. These files are not included in the import. Complete the steps in section 5.2.2.2.2 Define Device Profile Type Files define the static firmware files and to upload the firmware.
  • Page 33 Define Device Profile Type Files This section describes the BroadWorks Device Management configuration necessary to identify the configuration files and other files that the Spectralink IP-DECT Server Series download. Configuration templates, firmware, and other files the IP-DECT Server uses must be uploaded to BroadWorks.

  • Page 34: Figure 5 %Bwmacaddress%-Config.xml File Settings

    After creating the device profile type file, upload %BWMACADDRESS%-config.xml, which is extracted from the CPE kit obtained from Spectralink. Use the Browse button on the file definition screen. Be sure to click Apply after uploading the file. Figure 5 %BWMACADDRESS%-config.xml File Settings 5.2.2.2.2.2...

  • Page 35: Figure 6 %Bwmacaddress%-Users.xml File Settings

    Figure After creating the device profile type file, upload 14218500-ipdect-firmware-<Firmware Version>.bin, which is extracted from the CPE kit obtained from Spectralink. Use the Browse button on the file definition screen. Be sure to click Apply after uploading the file. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 ©...

  • Page 36: Figure 7 14218500-Ipdect-Firmware-.Bin File Settings

    Figure After creating the device profile type file, upload 14218500-ipdect-firmware-<Firmware Version>.bin.ver, which is extracted from the CPE kit obtained from Spectralink. Use the Browse button on the file definition screen. Be sure to click Apply after uploading the file. BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 ©...

  • Page 37: Create Device Profile Instance

    BroadWorks interface to an individual Spectralink device. Browse to the BroadWorks <group> → Resources → Identity/Device Profiles page and then select Add to add a new Spectralink IP-DECT Server Series device profile. Configure the device profile as shown in the example.

  • Page 38: Configure Broadworks User

    5.2.5 Customize Tags This section identifies custom tags used by the Spectralink that may need to be customized at the group or device profile. Customizing a tag at the group level overrides the setting on the device profile type for the device profiles created within the group.

  • Page 39: Configure Spectralink Ip Dect Server

    Figure 10 Custom Tags 5.2.6 Configure Spectralink IP DECT Server This section describes the steps necessary to configure the Spectralink IP DECT Server to integrate with BroadWorks Device Management. Browse to the web interface of the IP-DECT Server, http://<IP-DECT and log in. The default credentials are “admin/admin”.

  • Page 40: File Authentication Using Mac Address From Client Certificate

    BroadWorks Release 22.0. Prior to configuring for the MAC address authentication, mutual HTTPS authentication must be established among the Spectralink IP DECT server and BroadWorks. That is by the implication of client certificate authentication, HTTPS must be enabled on the DECT server to trust BroadWorks server certificate.

  • Page 41: Figure 12 Mac Address Definition For Device Profile Instance

    BroadWorks system. Prepare the authentication mode switch by collecting all MAC addresses of the existing Spectralink IP DECT Servers and follow instructions below in the specified order. 5.2.7.1...

  • Page 42: Figure 13 Device Profile Type Update For Mac-Based Authentication Using Client Certificate

    Change File Authentication Mode to MAC address in Client Certificate Instructions in this section are only applicable to updating BroadWorks systems with existing Spectralink IP DECT Server device profile types. Perform corresponding changes on the authentication mode of all files listed under section 5.2.2.2.2 Define Device Profile...

  • Page 43: Figure 14 Authentication Mode Set To Mac-Based And Sourced From Client Certificate

    Upgrade from Previous CPE Kits The previous configuration sections are primarily structured around importing or manually configuring the Spectralink device profile types for the first time. Many of the steps are unnecessary when upgrading to a new firmware release or CPE kit version.
  • Page 44 </auto> </mr> <network> <bootproto>%IP-DECT-NETWORK-BOOTPROTO%</bootproto> <ipaddr>%IP-DECT-NETWORK-IPADDR%</ipaddr> <dns1>%DNS_SERVER_1%</dns1> <dns2>%DNS_SERVER_2%</dns2> <gateway>%IP-DECT-NETWORK-GATEWAY%</gateway> <ipv6> <gateway>%IP-DECT-NETWORK-IPV6-GATEWAY%</gateway> <ipaddr>%IP-DECT-NETWORK-IPV6-IPADDR%</ipaddr> <method>%IP-DECT-NETWORK-IPV6-METHOD%</method> </ipv6> <netmask>%IP-DECT-NETWORK-NETMASK%</netmask> <ntp>%SNTP_SERVER%</ntp> <timezone>%IP-DECT-TIMEZONE%</timezone> </network> <phonebook> <ldap_attributes>%IP-DECT-PHONEBOOK-LDAP-ATTRIBUTES%</ldap_attributes> <ldap_base>%IP-DECT-PHONEBOOK-LDAP-BASE%</ldap_base> <ldap_bind_password>%IP-DECT-PHONEBOOK-LDAP-BIND- PASSWORD%</ldap_bind_password> BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 44 OF 49...
  • Page 45 </auto> </rfp> <security> <allow_http>%IP-DECT-SECURITY-ALLOW-HTTP%</allow_http> <allow_new_media_resource>%IP-DECT-SECURITY-ALLOW-NEW- MR%</allow_new_media_resource> <allow_new_rfp>%IP-DECT-SECURITY-ALLOW-NEW-RFP%</allow_new_rfp> <password>%IP-DECT-SECURITY-PASSWORD%</password> <password_lifetime>%IP-DECT-SECURITY-PASSWORD- LIFETIME%</password_lifetime> <strict_password>%IP-DECT-SECURITY-STRICT-PASSWORD%</strict_password> <username>%IP-DECT-SECURITY-USERNAME%</username> <allow_new_rfp_as_active>%IP-DECT-SECURITY-ALLOW-NEW-RFP-AS- ACTIVE%</allow_new_rfp_as_active> <allow_new_media_resource_as_active>%IP-DECT-SECURITY-ALLOW-NEW-MEDIA- RESOURCE-AS-ACTIVE%</allow_new_media_resource_as_active> <rfp_encryption>%IP-DECT-SECURITY-RFP-ENCRYPTION%</rfp_encryption> <media_resource_encryption>%IP-DECT-SECURITY-MEDIA-RESOURCE- ENCRYPTION%</media_resource_encryption> <passwords_unexportable>%IP-DECT-SECURITY-PASSWORDS- UNEXPORTABLE%</passwords_unexportable> </security> BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 45 OF 49...
  • Page 46 <!-- Device ID:"%BWFQDEVICEID%" Generated:"%BWTIMESTAMP%" --> <users> <user> <standbytext>%BWFIRSTNAME-1%</standbytext> <username>%BWLINEPORT-1%</username> <displayname>%BWNAME-1%</displayname> <authpassword>%BWAUTHPASSWORD-1%</authpassword> <authuser>%BWAUTHUSER-1%</authuser> </user> <user> <standbytext>%BWFIRSTNAME-2%</standbytext> <username>%BWLINEPORT-2%</username> <displayname>%BWNAME-2%</displayname> <authpassword>%BWAUTHPASSWORD-2%</authpassword> <authuser>%BWAUTHUSER-2%</authuser> </user> <user> <standbytext>%BWFIRSTNAME-3%</standbytext> <username>%BWLINEPORT-3%</username> <displayname>%BWNAME-3%</displayname> BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 46 OF 49...
  • Page 47 <username>%BWLINEPORT-9%</username> <displayname>%BWNAME-9%</displayname> <authpassword>%BWAUTHPASSWORD-9%</authpassword> <authuser>%BWAUTHUSER-9%</authuser> </user> <user> <standbytext>%BWFIRSTNAME-10%</standbytext> <username>%BWLINEPORT-10%</username> <displayname>%BWNAME-10%</displayname> <authpassword>%BWAUTHPASSWORD-10%</authpassword> <authuser>%BWAUTHUSER-10%</authuser> </user> <user> <standbytext>%BWFIRSTNAME-11%</standbytext> <username>%BWLINEPORT-11%</username> <displayname>%BWNAME-11%</displayname> <authpassword>%BWAUTHPASSWORD-11%</authpassword> <authuser>%BWAUTHUSER-11%</authuser> </user> <user> <standbytext>%BWFIRSTNAME-12%</standbytext> <username>%BWLINEPORT-12%</username> BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 47 OF 49...
  • Page 48 <displayname>%BWNAME-12%</displayname> <authpassword>%BWAUTHPASSWORD-12%</authpassword> <authuser>%BWAUTHUSER-12%</authuser> </user> </users> BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES 20-BD5445-00 © 2019 BROADSOFT INC. PAGE 48 OF 49...
  • Page 49 References [1] Spectralink, Inc. 2014. Spectralink IP DECT Server 200/400/6500 Installation and Configuration Guide. Available from Spectralink at support.spectralink.com. [2] BroadSoft, Inc. 2018. BroadWorks Device Management Configuration Guide, Release 22.0. Available from BroadSoft at xchange.broadsoft.com. [3] BroadSoft, Inc. 2017. BroadWorks Redundancy Guide, Release 22.0. Available from BroadSoft at xchange.broadsoft.com.
