SpectraLink IP-DECT 200 Installation And Configuration Manual page 141

Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
Field
User - SIP
Username/Extension
Domain (Optional)
Displayname (Optional)
Authentication user (Optional)
Authentication password
(Optional)
User - Features
Call forward unconditional
(Optional)
14215700-IG, Edition 8.0
April 2018, Original document
Setting
Must contain information used for SIP registration etc.
E.g. the "user" in a SIP URI.
Enter the domain part of a SIP URI.
E.g. example.org in
John Doe<sip:1234@example.org>
Note: If not configured, the default domain entered under
SIP configuration will be used.
Enter the name of the user (e.g. caller ID).
E.g. John Doe in
John Doe<sip:1234@example.org>
Note: If Cisco Unified CM (Advanced Features) License
is loaded, the Cisco Unified CM will not use this, but it
may ease the administration of users within the Spec-
tralink IP-DECT Server.
Enter the user ID of the end user.
E.g. JohnDoe or 5208.
Note: The user name will override the Default User field
under SIP Configuration.
Priority:
1. Authentication user set for individual users
2. Authentication user set in server SIP settings
3. User name set for individual users
Enter the digest credential of the end user.
Note: The password will override the Default Password
field under SIP Configuration.
A Call Forward Unconditional (an extension to forward
calls to) can be added/removed via the web based Admin-
istration Page.
141
