Summary of Contents for SpectraLink IP-DECT 200

Page 1 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 14215700-IG, Edition 8.0 April 2018, Original document...
Page 2 The drawings and specifications contained herein are the property of Spectralink and shall be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
Page 3: Table Of Contents
Terminology and Acronyms About DECT DECT Frequency Bands Spectralink IP-DECT Server Solution Types of Servers Description - Spectralink IP-DECT Server 200 Description - Spectralink IP-DECT Server 400 Description - Spectralink IP-DECT Server 6500 Other Solution Components Description - Spectralink DECT Media Resource...
Page 4 Spectralink IP-DECT Server 200 LED Indicators Front Cover LAN Port on Face Plate Spectralink IP-DECT Server 200 Reset Button Wall-Mount and Power on the Spectralink IP-DECT Server 200 Installing the Spectralink IP-DECT Server 400 Installing the Spectralink IP-DECT Server 6500 and Spec- tralink DECT Media Resource...
Page 5 Kit Content of the Spectralink Repeater Programming Kit Set up of the Hardware for Repeater Programming Programming the Spectralink DECT Repeater with the Handset and Repeater Management Tool Numbering of Base Stations/Server 200/400 and Repeaters in a Normal Con-...
Page 6 Defining a Cluster for the Media Resource and Base Stations Assigning Media Resources to Clusters Assigning Base Stations to Clusters Assigning Server Address to Spectralink IP-DECT Base Station and Spectralink DECT Media Resource Manually IP-DECT Server Address Configuration for Base Stations...
Page 7 To Update Spectralink IP-DECT Server Firmware To Update Spectralink IP-DECT Base Station Firmware To Update Spectralink DECT Media Resource Firmware To Update Spectralink DECT Handset Firmware Over The Air (SUOTA) Restarting System or Block Calls during Firmware Update To Restart System or Block New Calls...
Page 8 Configuring a Backup Spectralink IP-DECT Server 6500 Base Station and Media Resource Configuration Administration Scenarios Upgrading an Existing Spectralink IP-DECT Server 6500 Solution into a Redundant Solution Temporary Failure on the Master Spectralink IP-DECT Server 6500 Permanent Failure on the Master Spectralink IP-DECT Server 6500...
Page 9 Product Compatibility Troubleshooting Packet Capture Network Diagnose Parameter Overview Status - General Status - Logs Status - Wireless Server Status - Packet Capture Status - Network Diagnose Configuration - General Configuration - Wireless Server Configuration - Media Resource Configuration - Security Configuration - Certificates Configuration - SIP Configuration - Redundancy...
Page 10: About This Guide
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide About This Guide This guide is intended for qualified technicians who will install, configure and maintain the Spectralink IP-DECT Server 200/400/6500 solution. To qualify to install the Spectralink IP-DECT Server 400/6500 solution, you must have successfully completed the Spectralink IP-DECT Server 400/6500 technical training.
Page 11: Related Documentation
Available online at http://support.spectralink.com/products. Spectralink DECT Training material In order to gain access to the Spectralink training mater- ial, you must attend training and become Spectralink Cer- tified Specialist. Please visit http://- partneraccess.spectralink.com/training/classroom-train-...
Page 12: Terminology And Acronyms
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Terminology and Acronyms The table below refers to common terms and acronyms that are related to the Spectralink IP-DECT solutions. Term Definition Authentication Code Access Rights Identity - Wireless identity of the Spectralink IP-DECT/DECT Server.
Page 13 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Term Definition Local Area Network LAN synchronization Method for synchronizing IP base stations over LAN Light Emitting Diode Li-ion Lithium-ion Media Access Control - hardware address of a device con- nected to a network...
Page 14 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Term Definition Site survey A site survey comprises the act of locating the best places for base stations by measuring RSSI levels with DECT handsets. Complete survey consists of measuring with mul- tiple base stations, combining RSSI and Q value reading in real surroundings.
Page 15: About Dect
10mW, but can deliver a burst power output of 250mW. Note: The entire Spectralink 7000 Portfolio is built on DECT technology. DECT Frequency Bands The following frequency bands are dedicated to DECT: EMEA, Australia &...
Page 16: Spectralink Ip-Dect Server Solution
Description - Spectralink IP-DECT Server 200 The Spectralink IP-DECT Server 200 is a single cell system (one built-in base station in the server) supporting SIP lines only. The Spectralink IP-DECT Server 200 is designed with connector for External Antenna.
Page 17: Description - Spectralink Ip-Dect Server 400
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Description - Spectralink IP-DECT Server 400 The Spectralink IP-DECT Server 400 is in its basic edition a single cell system (one built-in base sta- tion in the server) supporting SIP lines only.
Page 18: Description - Spectralink Ip-Dect Server 6500
A Spectralink IP-DECT Server 6500 is installed directly on the LAN and must be managed as part of the corporate network. The Spectralink IP-DECT Server 6500 is a multi cell solution in a 19” cabinet. It is shipped from the factory as an Spectralink IP-DECT Server 6500 with one Ethernet port and 32 on-board speech channels, which allows for up to 32 full duplex simultaneous media streams (RTP streams) depend- ing on the codec being used.
Page 19: Other Solution Components
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Other Solution Components In addition to the Spectralink IP-DECT Server, a Spectralink IP-DECT Server configuration can include a number of the following components: Spectralink DECT Media Resources (only Spectralink IP-DECT Server 6500) Spectralink IP-DECT Base Stations (only Spectralink IP-DECT Server 400/6500)
Page 20: Description - Spectralink Dect Media Resource
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Description - Spectralink DECT Media Resource The Spectralink DECT Media Resource is a print board that is placed within the same rack next to the Spectralink IP-DECT Server 6500 board. Up to 2 Spectralink DECT Media Resources can be placed in the same rack that houses the Spectralink IP-DECT Server 6500 board.
Page 21: Description - Spectralink Ip-Dect Base Station
The DECT radius of coverage is up to 600 meters/2000 feet with a handset in free sight. Description - Spectralink DECT Repeater The Spectralink DECT Repeater is a building block to be used to extend the coverage area in a wire- less Spectralink DECT solution. The repeater does not increase the number of traffic channels, how-...
Page 22 Spectralink IP-DECT Servers with a built-in Spectralink IP-DECT Base Station. The repeaters are mainly used in areas with limited traffic. The Spectralink DECT Repeater is avail- able with either 2 or 4 voice channels. It is wireless and does not need physical connection to the Spectralink IP-DECT/DECT Server, making it very easy to install.
Page 23: Description - External Antenna
Spectralink IP-DECT Server 200/400 for added coverage in complex environments or to link up with remote areas. External antennas can also be used with Spectralink DECT Repeaters to link up with remote areas where wiring between the server and base station is difficult or impossible.
Page 24: System Capacity Overview
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide System Capacity Overview Below you will find an overview of the system capacity of the Spectralink IP-DECT Server: System Capacity - Servers Description IP-DECT Server 400 IP-DECT Server 6500 IP-DECT Servers Media Resources...
Page 25: Spectralink Server Solution Overview And Comparison
Spectralink Server Solution Overview and Comparison Product Overview *) The Spectralink IP-DECT Server 200/400 has a built-in radio which acts like an Spectralink IP- DECT Base Station with up to 12 speech channels. **) Spectralink Digital DECT Base Stations are available in the following editions: RFP4 and RFP5 (4 speech channels) and RFP6 (4 or 8 speech channels).
Page 26: Spectralink Handset Portfolio Overview
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink Handset Portfolio Overview For more information about the handsets, see the relevant Handset User Guides. Total Configuration Overview 14215700-IG, Edition 8.0 April 2018, Original document...
Page 27: Server Comparison Matrix
The illustration below shows a Spectralink 7000 Portfolio Infrastructure/Spectralink Server com- parison matrix. *) 4 channel/8 channel Spectralink Digital DECT Base Station. **) The Spectralink IP-DECT Server 200/400 has a built-in radio which acts like an Spectralink IP- DECT Base Station with up to 12 speech channels. 14215700-IG, Edition 8.0...
Page 28 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide ***) External antenna can only be used with Spectralink IP-DECT Server 200/400, RFP 6 Spec- tralink Digital DECT Base Stations, Spectralink IP-DECT Base Stations and Spectralink DECT Repeaters. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 29: Base Station Comparison Matrix
The illustration below shows a Spectralink Base Station comparison matrix. In the comparison mat- rix you see the currently most used Spectralink base stations and the difference between them. Only the Spectralink IP-DECT Base Station and the RFP6 Spectralink Digital DECT Base Station are in production.
Page 30 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Note: It is possible to use LAN synchronization for Spectralink IP-DECT Base Station instead of Radio synchronization (Over The Air). This requires installation of a LAN Syn- chronization License. For more information, see "LAN Based Synchronization (License...
Page 31: Configuration Overview - Spectralink Ip-Dect Server 200
Configuration Overview - Spectralink IP-DECT Server The Spectralink IP-DECT Server 200 is typically configured as illustrated below: The Spectralink IP-DECT Server 200 connects with Ethernet as well as the IP-PBX and 3rd party application server. Optional wireless repeaters can be used to extend the coverage of the Spectralink IP-DECT Server 200.
Page 32 The Spectralink IP-DECT Server 400 is typically configured as illustrated below: The Spectralink IP-DECT Server 400 connects with Ethernet as well as the IP-PBX and 3rd party application server. The optional Spectralink IP-DECT Base Stations are controlled by the Spec- tralink IP-DECT Server 400.
Page 33: Configuration Overview - Spectralink Ip-Dect Server 6500
The Spectralink IP-DECT Server 6500 is typically configured as illustrated below: The Spectralink IP-DECT Base Stations connect with the Ethernet as well as the IP-PBX and 3rd party application server. The Spectralink IP-DECT Base Stations are controlled by the Spectralink IP-DECT Server 6500.
Page 34: Communication Ports - Spectralink Ip-Dect Server
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Communication Ports - Spectralink IP-DECT Server The Spectralink IP-DECT Server utilizes a number of different protocols and ports on the network (see illustration below). These ports MUST not be blocked by firewalls or other network equipment.
Page 35: Communication Ports - Spectralink Ip-Dect Server 400/6500
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Communication Ports - Spectralink IP-DECT Server 400/6500 The Spectralink IP-DECT Server utilizes a number of different protocols and ports on the network (see illustration below). These ports MUST not be blocked by firewalls or other network equipment.
Page 36 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Example of protocols and ports for a Spectralink IP-DECT Server 400: *) Default configurable **) If SIP per port registration is checked = 5060 + X (Number of SIP Registrations) Spectralink IP-DECT Server 400 system can utilize the following protocols:HTTP/HTTPS, FTP/TFTP, UPnP, MSF (TCP port 56003), syslog (UDP port 514), NTP, LDAP and SNMP.
Page 37: Service Codes - Spectralink Ip-Dect Server
IP address - enter ***999*00 MAC addres - enter ***999*01 Server firmware ***999*02 Note: If UPnP is enabled, all Spectralink IP-DECT Servers can be identified on the network by their serial number. For more information, see "Discovering the Spectralink IP-DECT Components via UPnP" on page 87.
Page 38: Licenses
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Licenses Licenses can be purchased to enable additional features on the Spectralink IP-DECT Server 200/400/6500. Some of the licenses are specific to the servers, some are common. In the following you will find information about:...
Page 39: Licenses For Spectralink Ip-Dect Server 400/6500
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Licenses for Spectralink IP-DECT Server 400/6500 Licenses Description Server 400 Server 6500 12 Channels + 30 Users | IP- Allows for up to 30 users and DECT Server 400 up to 6 speech channels.
Page 40 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Licenses Description Server 400 Server 6500 Multicell | IP-DECT Server 400 Allows: (1407 5520) Up to 12 users. Up to 3 additional base sta- tions. Increases the number of chan- nels enabled from 6 to 12.
Page 41 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Licenses Description Server 400 Server 6500 Cisco Unified CM (Advanced Allows for tighter integration Features) | IP-DECT Server with the Cisco Unified Com- 6500 munications Manager and addi- tional features. (1407 5495)
Page 42 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Licenses Description Server 400 Server 6500 4096 Users | IP-DECT Server Allows for up to 4096 users. 6000/6500 (1407 5240) Lync/SfB +Security (TLS, Allows for integration with SRTP) | IP-DECT Server Microsoft Skype for Business 6000/6500 and additional features.
Page 43: Ordering Licenses
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Ordering Licenses 1. Send your Purchase Order (PO) including the software part number and the number of licenses needed to Spectralink Order Management via (EMEA and APAC) emeaom@spec- tralink.com or (NALA) nalaom@spectralink.com 2.
Page 44: Installation Requirements
Safety and Handling information is available online at http://support.spectralink.com/products. All Spectralink documents are available at http://support.spectralink.com/products. Requirements for Spectralink IP-DECT Server 200/400 The Spectralink IP-DECT Server 200/400 is a combined Spectralink IP-DECT Base Station and server. For more information about requirements, see "Requirements for Spectralink IP-DECT Base Sta-...
Page 45: Requirements For Spectralink Ip-Dect Base Station And Spectralink Dect Repeater
PoE power source. Use an 8V-DC power supply when using a port without PoE. For more information about installing the Spectralink IP-DECT Base Station and Spectralink DECT Repeater, see "Installing the Spectralink IP-DECT Base Station" on page 62 "Installing the...
Page 46: Requirements For Spectralink Dect Handset
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Requirements for Spectralink DECT Handset For more information about the handset, refer to the user guide available online at http://sup- port.spectralink.com/products. Requirements for Spectralink Maintenance Software Software Requirements The following is required to run the handset and repeater installation and maintenance tools.
Page 47: Installation Prerequisites
Before you start the installation, you need to find the following information and perform the following tasks: ARI for the Spectralink IP-DECT Server (see label on the rear of the server unit) For more information, see "Identifying ARI on Spectralink IP-DECT Server" on the next page.
Page 48: About Ari And Ipei Identification
A Spectralink IP-DECT Server uses an Access Right Identity number, also called ARI number, for server identification. When an IPEI number of a handset is linked to a Spectralink IP-DECT Server, the handset is sub- scribed. There is a record in the Spectralink IP-DECT Server holding information about all the hand- sets being subscribed to it.
Page 49: Power Requirements For The Spectralink Ip-Dect Server
Use a standard PoE adapter or a PoE-enabled port on an ethernet switch adhering to PoE 802.3af when connecting the Spectralink IP-DECT Server 200 to a PoE power source. Use an 8V-DC power supply when using a port without PoE.
Page 50: Spectralink Ip-Dect Server 200 Appearance And Components
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink IP-DECT Server 200 Appearance and Com- ponents Below you will find a description of the Spectralink IP-DECT Server 200 appearance and com- ponents: Spectralink IP-DECT Server 200 - bottom Spectralink IP-DECT Server 200 - rear...
Page 51: Spectralink Ip-Dect Server 200 Led Indicators
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink IP-DECT Server 200 - front Spectralink IP-DECT Server 200 LED Indicators Below you will find information about LED indicators on the server. Front Cover The server front cover has one indicator describing the server faults and failures. The indicator is off when the server is not powered.
Page 52: Lan Port On Face Plate
Activity Spectralink IP-DECT Server 200 Reset Button You can restart or reset the Spectralink IP-DECT Server 200 by pressing the Reset button on the bottom of face plate of the server. The following table contains a description of the different actions that take place when pressing the Reset button.
Page 53 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Holes for wall mounted screws RJ45 port 2. Connect the RJ45 plug to the ethernet connector at the bottom of the Spectralink IP-DECT Server 200. 3. After installing the Spectralink IP-DECT Server 200 you need to power it up.
Page 54: Installing The Spectralink Ip-Dect Server
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Installing the Spectralink IP-DECT Server The Spectralink IP-DECT Server 400 is a combined Spectralink IP-DECT Base Station and server. For more information about appearance and components, Reset Button and mounting, see "Installing the Spectralink IP-DECT Base Station" on page 62.
Page 55: Installing The Spectralink Ip-Dect Server 6500 And Spectralink Dect Media Resource
The Spectralink IP-DECT Server 6500 comes with one built-in media resource. Before you install the equipment, ensure that a site planner defines the locations of the Spectralink IP-DECT Server 6500 and Spectralink DECT Media Resources.
Page 56: Server And Media Resource Led Indicators
The Spectralink IP-DECT Server 6500/Spectralink DECT Media Resource front cover has one indic- ator describing the faults and failures of the device. The indicator is off when the Spectralink IP- DECT Server 6500/Spectralink DECT Media Resource is not powered. The LED flashes when the Spectralink IP-DECT Server 6500/Spectralink DECT Media Resource initializes.
Page 57: Server And Media Resource Reset Button
Mounting in a Rack The Spectralink IP-DECT Server 6500/Spectralink DECT Media Resource is mountable in a rack. 1. Mount the two wings with the screws. If you are mounting the Spectralink IP-DECT Server 6500 on a wall, twist the wings 90° degrees.
Page 58: Adding Aditional Spectralink Dect Media Resources
Below is an image of the Spectralink IP-DECT Server 6500 cabinet. The Spectralink IP-DECT Server 6500 itself resides to the far left, which is standard, and the two optional Spectralink DECT Media Resources reside in the middle and to the far right.
Page 59: How To Add A Spectralink Dect Media Resource
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide How to Add a Spectralink DECT Media Resource 1. Remove the top cover from the cabinet. 2. Unpack the media resource board. 3. Cut a hole for the RJ45 network connector in the front foil of the cabinet.
Page 60 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 5. Prepare the media resource power connector. 6. Connect the power cable to the media resource power connector. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 61 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 7. Close the cabinet again. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 62: Installing The Spectralink Ip-Dect Base Station
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Installing the Spectralink IP-DECT Base Station Below you will find information about installing the base station. Note: Before you install the equipment, ensure that a site planner defines the location of the base stations.
Page 63: Base Station Appearance And Components
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Base Station Appearance and Components Below you will find a description of the base station appearance and components: Spectralink IP-DECT Base Station - rear Holes for wall mounted screws Connection to LAN IP-DECT Base Station - front 14215700-IG, Edition 8.0...
Page 64 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide IP-DECT Base Station Reset button LINK/Activity Indicator ETH port (power supply by PoE) 14215700-IG, Edition 8.0 April 2018, Original document...
Page 65: Base Station Led Indicators
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Base Station LED Indicators Below you will find information about LED indicators on the base station. Front Cover The base station front cover has one indicator describing the base station faults and failures. The indicator is off when the base station is not powered.
Page 66: Mounting The Base Station
Do not mount the base station on soft surfaced walls such as those covered with canvas, metal or sponge-like materials. How to Wall Mount the Spectralink IP-DECT Base Station The base station must be mounted vertically on the wall for best coverage.
Page 67 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Holes for wall mounted screws RJ45 port 3. Connect the network cable to the RJ45 port. 4. After installing the base station you need to power it up. For more information, see "Power...
Page 68: Installing The Spectralink Dect Repeater
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Installing the Spectralink DECT Repeater This section describes the Spectralink DECT Repeater and how to unpack and install it. Installing repeaters requires a software installation as well as a hardware installation. Note: Before you install the equipment, ensure that a site planner defines the location of the repeaters.
Page 69: Repeater Appearance And Components
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Repeater Appearance and Components Below you will find a description of the repeater appearance and components: DECT Repeater - bottom DECT Repeater - rear RJ9 port Holes for wall mounted screws External antenna connector DECT Repeater - front 14215700-IG, Edition 8.0...
Page 70: Repeater Led Indicators
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Repeater LED Indicators Below you will find information about LED indicators on the repeater. Front Cover LED Indicator Meaning Indicator Off The repeater is not powered. Flashing Repeater has been powered, sync has still not been established.
Page 71: How To Wall Mount The Repeater
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide How to Wall Mount the Repeater For best RF coverage, the device must be mounted vertically on walls. Caution: The repeater and external antenna is to be fixed-mounted on indoor permanent struc-...
Page 72: Programming A Spectralink Dect Repeater With The Repeater Programming Kit
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Programming a Spectralink DECT Repeater with the Repeater Programming Kit Content of the Spectralink Repeater Programming Kit The Repeater Programming Kit (Part no. 0250 9210) consists of: Splitter Programming tool with RJ-Connector...
Page 73: Programming The Spectralink Dect Repeater With The Handset And Repeater Management Tool
The Handset and Repeater Management Tool identifies the type of repeater, and with this software it is possible to program the Spectralink DECT Repeater to connect to the Spectralink DECT Radio Infrastructure solutions.
Page 74: Numbering Of Base Stations/Server 200/400 And Repeaters In A Normal Con- Figuration
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Numbering of Base Stations/Server 200/400 and Repeaters in a Normal Con- figuration Note: Repeater and base station/server RPNs must not be the same. Also, in a situation where common overlap is present between the actual units, a repeater cannot have an RPN that is similar to that of a base station/server or another repeater.
Page 75: Numbering Of Repeaters In A Repeater Daisy Chain Configuration
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Numbering of Repeaters in a Repeater Daisy Chain Configuration First Repeater in Chain RPN of base station/server 200/400 + 64 Base to synchronize on: RPN of base station/server Second Repeater in Chain...
Page 76: Using The Spectralink Dect Repeater With External Antenna
Spectralink DECT Repeater. Note: Only the Spectralink external antenna (part no. 0231 9705 - including 1 m connection cable) is approved along with the Spectralink DECT Repeater. The external antenna is delivered with a 1 m connection cable. The connection cable is also available in 3 m (part no.
Page 77: Alternative Synchronization Ways
DECT Repeater will obtain synchronization on the alternative synchronization source. Alternative Synchronization Ways The Spectralink DECT Repeater with or without external antenna, 4 channels, can be programmed to obtain synchronization on two radio units (base station, wireless server 200/400 or repeater).
Page 78: Using The Spectralink Ip-Dect Server 200/400 And Spectralink Ip-Dect Base Station With External Antenna
3 m (part no. 1400 2704 and 7.5 m (part no. 1400 2706). The devices are automatically configured to the external antenna when connected. First example (see illustration below) is an example of using a Spectralink IP-DECT Base Station with external antenna.
Page 79 This scenario allows for coverage over very long distances. Third example (see illustration below) is an example of using external antenna only on a Spectralink IP-DECT Base Station or Spectralink IP-DECT Server 400 with built-in antenna turned off (requires Multicell | IP-DECT Server 400 License on the Spectralink IP-DECT Server 400).
Page 80 Fourth example (see illustration below) is an examle of using a Spectralink IP-DECT Server 400 (single cell solution) with external antenna. Fifth example (see illustration below) is an example of using a Spectralink IP-DECT Server 200 with external antenna. 14215700-IG, Edition 8.0...
Page 81: How To Connect External Antenna To Device
How to Connect External Antenna to Device Connect the external antenna cable to the antenna connector on the rear side of the Spectralink IP- DECT Base Stations and Spectralink IP-DECT Server 200/400 and in the same way on the external antenna.
Page 82: Configuration Steps Overview
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuration Steps Overview Below is an overview of the steps to follow in order to configure the Spectralink IP-DECT Server solu- tion after having installed all system components and completed all pre-configuration tasks.
Page 83 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Note: The above mentioned configuration steps are only the minimum steps for configuring a system and being able to make calls between two handsets. Depending on your solution, configuration of media resources, clusters, redundancy server, handset sharing, phone book and MSF messaging can also be part of further con- figuration.
Page 84: Configuring The Spectralink Ip-Dect Server/Spectralink Dect Media Resource Solution
Configuration of Spectralink IP-DECT Base Stations is not relevant to the Spectralink IP- DECT Server 200. The web based Administration Page is used to configure the different components of the Spectralink IP-DECT Server solution. Basic network settings can be obtained the following ways: From a DHCP server Using DHCP the device requests and obtains an available IP address from a DHCP server.
Page 85: Recommended Network Configuration
Administration Page of the Spectralink IP-DECT Server. If the Spectralink IP-DECT Server solution is configured as recommended above, it is possible to assign options to the DHCP server making it extremely easy to configure all media resources and base stations.
Page 86: Assigning Dhcp Server Options
(60) with the value KIRK.IP6000 and a request for the Vendor Specific Information option (43) in the initial DHCP Discover request. In the DHCP offer message, it will then expect the address of the Spectralink IP-DECT Server loc- ation in the Vendor Specific Information option (43), sub-option 43 encpapsulated as a string type parameter.
Page 87: Discovering The Spectralink Ip-Dect Components Via Upnp
Discovering the Spectralink IP-DECT Components via UPnP The Spectralink IP-DECT Server is setup with DHCP enabled by default. Therefore, you must use UPnP to discover the Spectralink IP-DECT Server. The Spectralink IP-DECT Server will appear under Network and Other Devices (using Windows Explorer) as "KWS6500 -<Serial number>...
Page 88: Assigning Dhcp Server Reservations
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Assigning DHCP Server Reservations If the Spectralink IP-DECT Server/ Spectralink DECT Media Resource is configured using DHCP, it is necessary to assign a reservation for the device on the DHCP server. For more information about this feature, contact your network administrator.
Page 89: About The Main Page Of The Web Based Administration Page
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide About the Main Page of the Web Based Administration Page The main page of the web based Administration Page for the Spectralink IP-DECT Server, Spec- tralink DECT Media Resource and Spectralink IP-DECT Base Station consists of menus and sub- menus.
Page 90 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink IP-DECT Base Station The web based Administration Page of the Spectralink IP-DECT Base Station can be used in the fol- lowing situations: Configuration - to specify to which Spectralink IP-DECT Server the Spectralink IP-DECT Base Station should connect.
Page 91: Configuring Network Settings
Note: As the Spectralink IP-DECT Server is a critical part of the SIP infrastructure, it is highly recommended that you do not use DHCP. Using a static IP address for the Spectralink IP-DECT Server is the preferred method. If the device is configured using a static IP address, it is possible to assign options to the DHCP server making it extremely easy to configure all base stations.
Page 92: To Configure A Dynamic Ip Address
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Configure a Dynamic IP address It is recommended to use a dynamic IP address (DHCP) for base stations. To configure network settings (dynamic IP address) for the base stations from the web based Admin- istration Page: 1.
Page 93: To Configure A Static Ip Address And Other Network Settings
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Configure a Static IP Address and Other Network Settings It is highly recommended to use a static IP address for the Spectralink IP-DECT Server and Spec- tralink DECT Media Resource. To configure IP address, DNS and NTP settings for the Spectralink IP-DECT Server and Spec- tralink DECT Media Resource from the web based Administration Page:...
Page 94 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting General Configuration - IPv6 Method (Optional) Default value: Disabled If not using IPv4, select Static to set the following set- tings manually: IPv6 address, Subnet Prefix Length, Default Gateway, Primary DNS Server, and Secondary DNS Server.
Page 95 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Primary Server (Optional) Enter the IP address of the Primary DNS server. Secondary Server (Optional) Enter the IP address of the Secondary DNS server. General Configuration - NTP (Network Time Protocol)
Page 96 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Level Log level to send via syslog. Possible values: emergency. critical, error, warning, notice, info or debug. Default value: Info Scope (Optional) Scope of syslog settings. If set to all, the settings will override any local settings on e.g.
Page 97: Simple Network Management Protocol (Snmp)
SNMPv2 IPV6 In addition to the general information mentioned above, specific Spectralink DECT information is available on the Spectralink IP-DECT Server only. This information is defined in a SPECTRALINK- IPDECT MIB, which includes the following groups of information: dectGeneralInfoGroup Objects which provide general information about the IP-DECT server.
Page 98 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Configure SNMP Settings 1. Click Configuration, and then click General. 2. On the General Configuration page, enter the following data: Field Setting General Configuration - SNMP Enabled If enabled, access to the SNMP is allowed, and the server will respond to (Optional) SNMP requests.
Page 99: Configuring Security Settings And Changing System Password
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Security Settings and Changing System Password It is recommended to change the password for the devices. To change the password and other security settings from the web based Administration Page of the different devices (server, base sta- tions and media resources): 1.
Page 100: Strict Password Requirements
Remove user passwords from If enabled, users passwords are prevented from being exported data (Optional) included when data are exported from the Spectralink IP- DECT Server,e.g. when exporting the user list to XML files or CSV files. Note: Enabling this will exclude the user database from full system backups.
Page 101: Configuring Sip And Ip-Pbx Settings
Setting SIP Configuration - General Local port Enter the local port number. The local port is the port on which the Spectralink IP- DECT Server listens for incoming SIP-signalling. The default local port number is 5060. Transport Transport mechanism used for SIP messages.
Page 102 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Send all messages to current If enabled, all non-REGISTER requests to the current registrar (Optional) registrar will be sent, when more proxies are available. Registration expire(sec) The maximum time between re-registrations. The regis- trar can signal a shorter time-out.
Page 103 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting TLS allow insecure (Optional) By default, UDP and TCP transports are disabled when TLS transport is the default. If this setting is enabled, UDP and TCP are allowed as fallback if TLS fails.
Page 104 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Tone duration(msec) Enter the time length of the tone in milliseconds. Default value: 270 msec SIP Configuration - Message waiting indication Enable indication (Optional) If enabled, MWI is displayed in the handset.
Page 105 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Enable media encryption If enabled, external SRTP is supported and optional. It (SRTP) (Only visible if Security must be negotiated with the remote endpoint. (TLS, SRTP) License is loaded) Note: If external SRTP is enabled, the number of avail-...
Page 106 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Provide Music-on-Hold If enabled, Music-on-Hold is played for the remote end. (Optional) Display status messages If enabled, call status messages are received in the hand- (Optional) set. '#' key ends overlap dialing...
Page 107 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 3. Click Save. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 108: Configuring Wireless Server Settings
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Wireless Server Settings You must configure the Spectralink IP-DECT Server to allow for subscription. If the system does not allow subscription, it is not possible to subscribe handsets. To Configure Wireless Server Settings To configure Wireless Server settings from the web based Administration Page: 1.
Page 109 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Wireless Server Configuration - Media resources (Not relevant to the Spectralink IP- DECT Server 200/400) Allow new (Optional) If enabled, new media resources are allowed to con- nect to the server.
Page 110 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Multicast signaling (Optional) Multicast signaling is optimal when having many base stations and is required with more than 256 base sta- tions connected. If enabled, this will impose multicast support for the net- work.
Page 111 64 = immediate 32 = priority 0 = routine (lowest priority) Default value: 184 (Expedited Forwarding) Wireless Server Configuration - Handsets (Not relevant to the Spectralink IP-DECT Server 200. Handset sharing (Optional) Enabled by default when Handset Sharing License is loaded.
Page 112 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field New password again (Optional) Confirm password required to access the application interface. Enable MSF (Optional) If enabled, access to the MSF application interface is supported. Default value: Disabled Enable XML-RPC (Optional) If enabled, access to the XML-RPC application inter- face is supported.
Page 113 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Enable Long-Press Key2 - Phone- If enabled, allow DECT Server to use this long key book (Optional) press for phone book. Enable Long-Press Key3 - Phone- If enabled, allow DECT Server to use this long key book (Optional) press for phone book.
Page 114 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 3. Click Save. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 115: Configuring Media Resource Settings
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Media Resource Settings Note: Not relevant to the Spectralink IP-DECT Server 200/400. To use the internal media resource, this must be enabled. To configure media resource settings from the web based Administration Page: 1.
Page 116: Configuring Certificates
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Certificates If using TLS as SIP transport method, it is necessary to import a CA certificate into the Spectralink IP-DECT/DECT Server from the web based Administration Page of the server. If using the trusted server functionality in a Lync/SfB environment or using TLS SIP transports in a Cisco Unified CM environment it is also necessary to import a host certificate.
Page 117 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Click Import List, if you want to import the list. It is also possible to; remove all CA certificates (Clear List), restore default list of public CA certificates (Restore Default List), or export the list of CA cer- tificates in PEM format (Export List).
Page 118: Configuring Clusters
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Clusters Note: Not relevant to the Spectralink IP-DECT Server 200/400. By default, the system will allocate a media channel on the media resource with the lowest load at the time a call is initiated. This can, however, lead to network traffic patterns that are not optimal in situations where base stations and media resource are located at different locations and/or in dif- ferent networks.
Page 119: Assigning Media Resources To Clusters
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Assigning Media Resources to Clusters To make use of the created cluster entities, these must be assigned to the physical media resources and base stations. The devices can be both local and remote.
Page 120: Assigning Base Stations To Clusters
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Assigning Base Stations to Clusters To make use of the created cluster entities, these must be assigned to the physical media resources and base stations. The devices can be both local and remote.
Page 121 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field External antenna mode Determines which antenna(s) are used when an external (Optional) antenna is connected. Possible values: Use Internal & external antenna, Use internal antenna only or Use external antenna only.
Page 122 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Base Station - RSSI map (Only visible if more than one base station on the system) RPN/RSSI dB/Offset Possible to see the RSSI values of the base stations the selected base station is synchronizing on (Primary syn- c/Secondary (Alternative) sync).
Page 123: Assigning Server Address To Spectralink Ip-Dect Base Station And Spectralink Dect Media Resource
Note: Not relevant to the Spectralink IP-DECT Server 200. After installation, it is necessary to assign a server address to the Spectralink IP-DECT Base Station and Spectralink DECT Media Resource through the web based Administration Page using either dynamic IP address (DHCP) or static IP address.
Page 124: Manually Ip-Dect Server Address Configuration For Media Resources
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Manually IP-DECT Server Address Configuration for Media Resources Note: Not relevant to the Spectralink IP-DECT Server 400. To configure the IP-DECT server address manually through the web based Administration Page of the media resource: 1.
Page 125: Administration Of Spectralink Ip-Dect Base Stations
To get an overview or in case of troubleshooting, it is possible to: check the synchronization state of the of the base station. For more information, see "Check- ing Sync State of Spectralink IP-DECT Base Station" on page 138. check for loops in the synchronization chain. For more information, see "Checking for Loops"...
Page 126: Using Multicast
The multicast IP address is fixed and uses 224.0.1.129 It is not possible to configure any of these parameters When a Spectralink IP-DECT Base Station is connected to a switch port it will announce itself by IGMPv3 (Internet Group Management Protocol). The Spectralink IP-DECT Base Station will then send a Membership report/Join group.
Page 127: Connecting Base Station To System
The above image shows a situation with no incoming calls to handsets, but only the keep-alive sig- nalling between server and base station. When an incoming call is received in the Spectralink IP-DECT Server, the server will send a mul- ticast packet. The multicast packet will contain the PP-ID of the handset. Each Spectralink IP-DECT Base Station will recive this multicast packet, and then send the page through the radio.
Page 128: Radio Based Synchronization
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Radio Based Synchronization You define the sync. ways of the Spectralink IP-DECT Base Station through the web based Admin- istration Page of the Spectralink IP-DECT Server. 1. Click Administration, then click Base Station, and then click on the relevant base station.
Page 129 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field External antenna mode Determines which antenna(s) are used when an external (Optional) antenna is connected. Possible values: Use Internal & external antenna, Use internal antenna only or Use external antenna only.
Page 130 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Base Station - RSSI map (Only visible if more than one base station on the system) RPN/RSSI dB/Offset Possible to see the RSSI values of the base stations the selected base station is synchronizing on (Primary syn- c/Secondary (Alternative) sync).
Page 131: Lan Based Synchronization (License Required)
Configuration Settings through the Web Based Administration Page A few configuration settings on the web based Administration Page of the Spectralink IP-DECT Server are used to control base station synchronization via LAN. 14215700-IG, Edition 8.0...
Page 132 Note: It is possible to define a TX power value for a specific base station (Administration > Base Sta- tion). Wireless Server Configuration - Media resources (Not relevant to the Spectralink IP- DECT Server 200/400) Allow new (Optional) If enabled, new media resources are allowed to con- nect to the server.
Page 133 PCS17Fa or newer to connect. If not enabled, the connection will be encrypted if the media resource supports encryption. Wireless Server Configuration - Base stations (Not relevant to the Spectralink IP- DECT Server 200. Allow new (Optional) If enabled, new base stations are allowed to connect to the server.
Page 134 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Multicast signaling (Optional) Multicast signaling is optimal when having many base stations and is required with more than 256 base sta- tions connected. If enabled, this will impose multicast support for the net- work.
Page 135 64 = immediate 32 = priority 0 = routine (lowest priority) Default value: 184 (Expedited Forwarding) Wireless Server Configuration - Handsets (Not relevant to the Spectralink IP-DECT Server 200. Handset sharing (Optional) Enabled by default when Handset Sharing License is loaded.
Page 136 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field New password again (Optional) Confirm password required to access the application interface. Enable MSF (Optional) If enabled, access to the MSF application interface is supported. Default value: Disabled Enable XML-RPC (Optional) If enabled, access to the XML-RPC application inter- face is supported.
Page 137 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Enable Long-Press Key3 - Phone- If enabled, allow DECT Server to use this long key book (Optional) press for phone book. Enable Long-Press Key4 - Phone- If enabled, allow DECT Server to use this long key book (Optional) press for phone book.
Page 138: Checking Sync State Of Spectralink Ip-Dect Base Station
You can get information about the synchronization state of the base station - the uptime and to which radio unit it synchronizes on through the web based Administration Page of the Spectralink IP- DECT Server. This is useful when you want to get an overview of the base stations and in case of problem solving.
Page 139: Registering Users And Subscribing Spectralink Dect Hand- Sets
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Registering Users and Subscribing Spec- tralink DECT Handsets You must register a user and subscribe a handset before you can use it. When registering users, you enter information about each user's settings (such as; IPEI, user- name (handset serial number), access code etc.) in the system database.
Page 140 A standby text is a fixed label shown in the top left part of the screen on the DECT handset when in idle state. Note: This feature is only available if Spectralink DECT handsets are being used. If third party DECT handsets are being subscribed, this feature is not supported.
Page 141 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting User - SIP Username/Extension Must contain information used for SIP registration etc. E.g. the "user" in a SIP URI. Domain (Optional) Enter the domain part of a SIP URI. E.g. example.org in John Doe<sip:1234@example.org>...
Page 142: Subscribing A Spectralink Dect Handset
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 4. Click Save. Subscribing a Spectralink DECT Handset Subscription of the Spectralink DECT Handset is performed from the menu in the handset. Note: You must configure the Spectralink IP-DECT Server to allow for subscription. If the sys- tem does not allow subscription, it is not possible to subscribe the handset.
Page 143: Handset Management
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Handset Management Some Handset management is performed using the web based Administration Page of the server. Management of the handsets, firmware and users can be performed from web based Admin- istration Page > Users > List Users.
Page 144: User List Information
Handset - Handset model Firmware - firmware version in handset Subscription - indicates if handset is subscribed to a Spectralink IP-DECT Server. Registration - indicates if handset is registered to a SIP server. Latest activity - last time the server has been in contact with the handset.
Page 145: Tasks To Perform From User List
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Tasks to Perform from User List Selecting one or more users from the list you can do the following: view or change handset/user configurations search handset/user information enable/disable users delete users re-register users...
Page 146: To Search Handset/User Information
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Search Handset/User Information You can search for a registered handset/user in the system through the web based Administration Page. 1. Click Users, and then click List Users. 2. In the Search field, enter relevant search string.
Page 147: To Update Handset Firmware
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Update Handset Firmware 1. Click Users, and then click List Users. 2. On the User List page, select the relevant user(s) from the list. 3. Click Firmware update. 4. On the Handset firmware update page, enter the following data:...
Page 148 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Import/Export Users - Import user data CSV format If you want to import user data, browse for the CSV file to import, and click Load. To be able to import the data correctly, the CSV file must contain certain information and punctuation.
Page 149: Example Of Handset Registration Data - Csv Format
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Example of Handset Registration Data - CSV Format You can import handset registration data in CSV format. To be able to import the data correctly, you must create a file containing the following information and punctuation:...
Page 150: System Management
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide System Management Through the web based Administration Page of the Spectralink IP-DECT Server it is possible to per- form the following system management: make a backup of configuration file update system firmware...
Page 151: Making A Back-Up And Restore Of System
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Making a Back-Up and Restore of System Through the web based Administration Page of the Spectralink IP-DECT Server it is possible to save the following data: configuration data of the Spectralink IP-DECT Server...
Page 152: Updating Firmware
To update the Spectralink DECT Handset using the Handset and Repeater Management Tool, acquisition of a Handset Management Cradle and download of Handset and Repeater Management Tool is required. Physical access to each Spectralink DECT Handset to be updated is also required.
Page 153: To Update Spectralink Ip-Dect Server Firmware
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Update Spectralink IP-DECT Server Firmware 1. Click Firmware, and then click Wireless Server. 2. On the Update firmware page, click Browse to find the relevant firmware file. Enable the Use firmware as default check box if you want the server firmware as default for all base stations and media resources (recommended).
Page 154: To Update Spectralink Ip-Dect Base Station Firmware
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Update Spectralink IP-DECT Base Station Firmware Note: Not relevant to the Spectralink IP-DECT Server 200. New firmware can be uploaded either through provisioning (license required) or manually. Note: Base stations can use default firmware, if selected when server firmware is uploaded.
Page 155 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Update base station firmware - Automatic Enable (Optional) Default value: Disabled Enable this, if you want to make automatic update possible. The base stations will be automatically updated using the default firmware.
Page 156 3. Click Update. Selected base stations will be updated. 4. Click Reboot base stations if you want to reboot selected base stations. Note: If Automatic update is not enabled, Spectralink IP-DECT Base Stations can be rebooted manually after they have been updated. 14215700-IG, Edition 8.0...
Page 157: To Update Spectralink Dect Media Resource Firmware
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide To Update Spectralink DECT Media Resource Firmware Note: Not relevant to the Spectralink IP-DECT Server 200/400. Once uploaded, default firmware will remain on the server until overwritten or deleted. New firmware can be uploaded either through provisioning (license required) or manually.
Page 158 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Update media resource firmware - Automatic Enable (Optional) Default value: Disabled Enable this, if you want to make automatic update possible. The media resources will be automatically updated using the default firmware.
Page 159: To Update Spectralink Dect Handset Firmware Over The Air (Suota)
Spectralink DECT Handset Butterfly can be updated over the air (SUOTA). The Spectralink DECT Handsets has a hardware platform that supports dual flash par- tition to ensure that the new firmware can be verified before it takes over from current run- ning firmware.
Page 160 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide 1. Click Firmware, and then click Handset. 2. On the Handset update settings page, enter the following data: Field Setting Handset update settings - Automatic update Enable (Optional) Enable. This will make automatic update possible.
Page 161: Restarting System Or Block Calls During Firmware Update
Restarting System or Block Calls during Firmware Update Through the web based Administration Page of the Spectralink IP-DECT Server it is possible to restart he Spectralink IP-DECT Server or block new calls during firmware update. To Restart System or Block New Calls 1.
Page 162: General Status Information
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Statistics (Wireless Server, Media Resource, Base Station, Active Calls, Abnormal Releases, Traffic Distribution) General Status Information This page provides general system information such as hardware and firmware information. 1. Click Status, and then click General. The General Status page appears.
Page 163: Logs Information
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Logs Information This page provides log information such as media resource connection, base station connection and different types of status. 1. Click Status, and then click Logs. The Message Log page appears.
Page 164: Wireless Server Information
3. Click Export if you want to save the logs in a file. Wireless Server Information This page provides information about the firmware version and ARI code of the Spectralink IP- DECT Server. 1. Click Status, and then click Wireless Server. The Wireless Server Status page appears.
Page 165 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Statistics of Wireless Server This page is useful to get information about traffic on the Spectralink IP-DECT Server such as voice call traffic and message call traffic and it provides a summary of subscription and handover statistics.
Page 166 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Statistics of Base Station This page is useful to get statistical information about the base station. Click Statistics, and then click Base Station. The Base Stations page appears. Statistics of Devices Click Statistics, and then click Device. The Devices page appears.
Page 167 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Statistics of Active Calls Click Statistics, and then click Active Calls. The Active Calls page appears. Statistics of Abnormal Releases This page is useful to get statistical information about abnormal releases. Click Statistics, and then click Abnormal Releases. The Abnormal call releases page appears.
Page 168: Changing Administration Password
Click Statistics, and then click Traffic Distribution. The Traffic Distribution page appears. Changing Administration Password From the web based Administration Page of the Spectralink IP-DECT Server it is possible to change the administration password. For more information, see "Configuring Security Settings and Changing System Password" on page 99.
Page 169 Remove user passwords from If enabled, users passwords are prevented from being exported data (Optional) included when data are exported from the Spectralink IP- DECT Server,e.g. when exporting the user list to XML files or CSV files. Note: Enabling this will exclude the user database from full system backups.
Page 170: Resetting System To Factory Settings
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Resetting System to Factory Settings Through the web based Administration Page of the Spectralink IP-DECT Server it is possible to reset the Spectralink IP-DECT Server to factory default settings (original configurations and empty user data base).
Page 171: Exporting/Importing Configuration File
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Exporting/Importing Configuration File Through the web based Administration Page of the Spectralink IP-DECT Server it is possible to export and import configuration file. To Import/Export Configuration File 1. Click Configuration, and then click Import/Export.
Page 172: Deleting Licenses
If you by mistake delete a license or perform a factory reset of the system (which will delete all loaded licenses), it is possible to retrieve the license(s) again by entering the ARI code of the Spectralink IP-DECT Server in the Spectralink License Key Generator on Spectralink Corporation's support portal: http://support.spectralink.com/keycode.
Page 173: Messaging Over Msf
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Messaging Over MSF With the MSF messages function you can send text messages to any MSF compatible handset con- nected to the Spectralink IP-DECT Server. XML-RPC SDK Documentation To setup the system to use MSF you must obtain the document “XML-RPC SDK” from the following e-mail address: aims@spectralink.com...
Page 174: Redundant System Configuration
Firmware Compatibility (Redundancy) For using a redundant server solution, it is required that the backup Spectralink IP-DECT Server has the same firmware revision and licensed features as the master Spectralink IP-DECT Server to be able to connect to the master.
Page 175: Design Of Redundant Server Solution
In a redundant Spectralink IP-DECT Server 6500 solution, the servers should be connected to separate switches, power groups etc. Below is an example design of a redundant Spectralink IP-DECT Server 6500 solution including a master Spectralink IP-DECT Server 6500 and a redundant backup Spectralink IP-DECT Server (slave server).
Page 176: How This Works
S for backup server (see image below): The users will not always be on the same system. After a reboot of the Spectralink IP-DECT Servers some of the users may have changed servers, there is no option to connect a specific user to a spe- cific server, this is done randomly by the system.
Page 177: Configuring Redundancy
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Redundancy Note: Not relevant to the Spectralink IP-DECT Server 400. This section describes how to configure a redundant server solution: Configuration of the redundancy feature requires the acquisition of redundancy licenses.
Page 178 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Note: If a license is installed on the master Spectralink IP-DECT Server 6500, a corresponding license with proper permissions must be installed on the backup Spectralink IP-DECT Server 6500 to enable the redundancy features.
Page 179 Authentication Product Key for your software license. The e-mail contains a txt document called “License.txt” and looks like this: 3. Find the System ARI Code for your master Spectralink IP-DECT Server6500 to be used in the License Key Generator. For more information, see "Identifying ARI on Spectralink IP-...
Page 180 The following Spectralink License Key Generator screen appears: 5. Generate the license for the master Spectralink IP-DECT Server 6500 by doing the following: In the ARI (DECT) / Serial number (Wi-Fi) field, enter the ARI of your master Spectralink IP-DECT Server.
Page 181 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide the e-mail you have entered. 6. Load the new license code using the web based Administration Page of the Spectralink IP- DECT Server. Click Administration, and then click License. Copy the provided license key from your email, paste it in the License field, and then click Load.
Page 182 Authentication Product Key for your software license. The e-mail contains a txt document called “License.txt” and looks like this: 3. Find the System ARI Code for your backup Spectralink IP-DECT Server6500 to be used in the License Key Generator. For more information, see "Identifying ARI on Spectralink IP-...
Page 183 The webpage will output the license and an email with the new license code will be sent to the e-mail you have entered. 6. Load the new license code using the web based Administration Page of the Spectralink IP- DECT Server.
Page 184 The Redundancy License had adopted the ARI code of the master Spectralink IP- DECT Server. This is done in the case of a failure of the master Spectralink IP- DECT Server, the backup Spectralink IP-DECT Server will have the same ARI code, and therefore the handsets will still be subscribed to the ARI, as this does not change.
Page 185: Configuring A Master Spectralink Ip-Dect Server 6500
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring a Master Spectralink IP-DECT Server 6500 The master Spectralink IP-DECT Server 6500 must be configured as a normal single server solution with base stations, media resources and users as “normal” and it must be verified that the desired functionality is working before enabling the redundancy feature, and the backup Spectralink IP- DECT Server 6500 is added.
Page 186 Redundancy Configuration - Settings Failover time(sec) Enter value for failover time. Failure time is the time in seconds from the Spectralink IP-DECT Server detects a failure, until it initiates a fail- over operation and cause the other peer to take over.
Page 187 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Note: Enabling or disabling the reduncancy funtion on a given server, will not require a reboot of the Spectralink IP-DECT Server(s). But, after clicking Save, all active calls can be dropped on base stations and media resources when the function is enabled/disabled as all media resources and base stations reconnect to the new setup.
Page 188: Configuring A Backup Spectralink Ip-Dect Server 6500
Configuring a Backup Spectralink IP-DECT Server 6500 On the backup Spectralink IP-DECT Server 6500 only basic network settings and redundancy set- tings need to be configured. All other settings are retrieved from the master Spectralink IP-DECT Server 6500. 1. Ensure that the Redundancy License is installed, and configured with basic network settings.
Page 189 Redundancy Configuration - Settings Failover time(sec) Enter value for failover time. Failure time is the time in seconds from the Spectralink IP-DECT Server detects a failure, until it initiates a fail- over operation and cause the other peer to take over.
Page 190: Base Station And Media Resource Configuration
Base Station and Media Resource Configuration The base stations and media resource should be configured just as in a single Spectralink IP-DECT Server 6500 solution, and the server address should be set to the address of the master Spectralink IP-DECT Server 6500.
Page 191: Administration Scenarios
Permanent Failure on the Master Spectralink IP-DECT Server 6500 If the master Spectralink IP-DECT Server 6500 has been damaged, lost or had its data erased, it will have to be replaced by the backup Spectralink IP-DECT Server 6500 in order to return the system to normal operation mode.
Page 192: Failure On The Backup Spectralink Ip-Dect Server 6500
The speed of re-registration depends on the PBX, and the load on the system. Failure on the Backup Spectralink IP-DECT Server 6500 A failure of the backup Spectralink IP-DECT Server 6500 will induce a short service outage, and the master Spectralink IP-DECT Server 6500 will reestablish full operation as a single server solution.
Page 193: Configuring Corporate Phone Book/Directory
The server can be configured in two ways: Retrieving phone book data using LDAP server. Configuration of the LDAP based phone book in the Spectralink IP-DECT Server is carried out through the web based Administration Page of the server. Importing phone book data from a CSV file.
Page 194 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Import Browse for the CSV file to import. Note: The CSV file must contain correct format. For more information, see "Example of CSV File Format" on page 196. Encoding Select the correct encoding for the CSV file. You can choose between UTF-8, ISO/IEC 8859-1 or Windows- 1252.
Page 195: Example Of Ldap Configuration
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Number attributes (Optional) Enter LDAP attributes that will be used to dial. E.g. telephoneNumber,mobile. Attributes names (Optional) Enter the attribute names you want to assign to the attrib- utes specified above, separated by a comma.
Page 196: Example Of Csv File Format
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Example of CSV File Format An example of a CSV file format for phone book data could be: "Label1","Label2","Label3","Label4","Label5" "Field1",”Field2”,"Field3","Field4","Field5" "Field1",”Field2”,"Field3","Field4","Field5" The labels are column names displayed in the handset. The fields are the actual data for the records.
Page 197: Handset Sharing
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Handset Sharing Note: Not relevant to the Spectralink IP-DECT Server 200. The traditional concept of a communication device is to have a device (phone) assigned to a number (SIP user). The basic concept of handset sharing is to break the link between the device and the user, and make it possible for any user to sign-in to any device.
Page 198 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide reasons. To use the handset sharing feature, the following is needed: Acquisition of the Handset Sharing License | IP-DECT/DECT Servers 400/6500/2500/8000. For more information, see "Adding Handset Sharing License | IP-DECT/DECT Servers 400/6500/2500/8000 "...
Page 199: Handset Sharing - Firmware Compatibility
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Handset Sharing - Firmware Compatibility Note: The handset sharing feature is available on all Spectralink Handsets. Not all fea- tures are supported in all models. Non-Spectralink Handsets do not support handset sharing.
Page 200: Configuration Overview - Spectralink Ip-Dect Server
Note: When a Handset Sharing License | IP-DECT/DECT Servers 400/6500/2500/8000 is loaded and the Spectralink IP-DECT/DECT Server is rebooted, the web based Admin- istration Page will display users differently than without a Handset Sharing License. The Users menu will have a List Users submenu and a List Devices submenu. The List users’...
Page 201: User Sign-In/Sign-Out
Using a sign-in procedure, it is possible to sign-in to the device and sign-out from the device from the handset instead of performing user administration from the web based Administration Page of the Spectralink IP-DECT Server. The advantage is, that no trusted server is required and no need for server user database synchronization to the Active Directory.
Page 202: Configuring Handset Login
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuring Handset Login Enable/Disable Handset Login on Spectralink IP-DECT Server 1. Ensure that support of the relevant call handler is enabled (Configuration > relevant Call handler (e.g. Skype for Business)). 2. Click Configuration, and then click Wireless Server.
Page 203 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Wireless Server Configuration - Media resources (Not relevant to the Spectralink IP- DECT Server 200/400) Allow new (Optional) If enabled, new media resources are allowed to con- nect to the server.
Page 204 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Multicast signaling (Optional) Multicast signaling is optimal when having many base stations and is required with more than 256 base sta- tions connected. If enabled, this will impose multicast support for the net- work.
Page 205 64 = immediate 32 = priority 0 = routine (lowest priority) Default value: 184 (Expedited Forwarding) Wireless Server Configuration - Handsets (Not relevant to the Spectralink IP-DECT Server 200. Handset sharing (Optional) Enabled by default when Handset Sharing License is loaded.
Page 206 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field New password again (Optional) Confirm password required to access the application interface. Enable MSF (Optional) If enabled, access to the MSF application interface is supported. Default value: Disabled Enable XML-RPC (Optional) If enabled, access to the XML-RPC application inter- face is supported.
Page 207 When invoking the Handset Login feature, a menu is presented allowing the user to select signing in with either extension and PIN (if configured) or with user name and password. Entering the required credentials will allow the Spectralink IP-DECT Server to connect the user to the Call handler and the handset will be ready for use.
Page 208: Signing Into A Device From The Handset
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Signing into a Device from the Handset When accessing the Sign in menu, you can choose between PIN Sign in or Sign in (PIN Sign in is only visible if PIN authentication is available and configured on the server of the call handler, e.g.
Page 209: Adding Devices To Server
Devices can be added and subscribed without any SIP users associated. Devices are identified by the IPEI, which is a globally unique number identifying the Spectralink Handset . Handsets can be added manually to the Spectralink IP-DECT Server by specifying an IPEI or they can be auto- matically created when subscribed to the Spectralink IP-DECT Server.
Page 210 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide When clicking on a User under the List Users menu, you see that the User profile is very similar to the User profile without Handset Sharing License installed. See image below. The IPEI field is still there, now with a new IPEI link and optional new PIN code field.
Page 211 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide On the Device profile, notice the Username / Extension link. If the handset is linked to a specific user, the text field will hold the extension number of that user and the Username / Extension link is active.
Page 212: Adding Users To Server
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Adding Users to Server Users are identified by their SIP username. User data are split in four categories: DECT device Mainly used for information about associated device (if any). Furthermore, by editing the IPEI it is possible for the administrator to “sign-in”...
Page 213: Handset Sharing And Provisioning
PIN code field is used during handset sign-in Once the Handset Sharing License is loaded onto the Spectralink IP-DECT Server, any handset can now be linked with any User at any given time, as long as that User is not linked with another hand- set.
Page 214 When clicking on an IPEI number under the Device List page, you see a Device profile which in essence is a unique handset, that has been subscribed to the Spectralink IP-DECT Server. The Device profile holds information about the handset’s IPEI number and optional access code used, when the handset is subscribed to the Spectralink IP-DECT Server.
Page 215 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Device (handset) and User are linked User is registered with SIP Server Above you see how a Device profile is linked to a User profile. Notice how the IPEI number and the Username / Extension number are associated, indicating a link between the Device and User.
Page 216: Example Of Setting Up Handsets For Handset Sharing
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Example of Setting Up Handsets for Handset Sharing 1. A Handset Sharing License | IP-DECT/DECT Servers 400/6500/2500/8000 must be loaded to the Spectralink IP-DECT Server. 2. Set up handset for Send MSF: Menu > Settings > Advanced > Long key > Send MSF.
Page 217: Product Compatibility
If you have any questions about product compatibility, contact your system administrator. You can use the Spectralink IP-DECT Server with other Spectralink products as identified by the type approval model ID and/or part number located on the label of the product.
Page 218 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink DECT Repeater Spectralink DECT Repeater 1G8, 2 channels, with K018B (0244 0000) connector for external antenna Spectralink DECT Repeater 1G9, 2 channels, with K018B (0244 1000) connector for external antenna Spectralink DECT Repeater 1G8, 2 channels,...
Page 219 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink Server Licenses for Server 400 12 Channels + 30 Users | IP-DECT Server 400 1407 5500 Lync/SfB +Security (TLS, SRTP) | IP-DECT 1407 5510 Server 400 Multicell | IP-DECT Server 400...
Page 220 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Spectralink Server Licenses for Server 6500 30 Users | IP-DECT Server 6000/6500 1407 5200 150 Users | IP-DECT Server 6000/6500 1407 5210 500 Users | IP-DECT Server 6000/6500 1407 5220 1500 Users | IP-DECT Server 6000/6500...
Page 221: Troubleshooting
Network Diagnose Reading System Information, Logs, Statistics etc. Checking synchronization chain for loops Note: For more in depth information and to gain access to the Spectralink training material, you must attend training and become Spectralink Certified Specialist. Please visit http://partneraccess.spectralink.com/training/classroom-training for more information and registration.
Page 222: Network Diagnose
4. If you want to stream a packet capture, click Stream. A pcap file is downloaded automatically. Note: The Spectralink IP-DECT Server has a packet capture size limit of 10 megabites. When this limit is reached, the packet capture will restart. When performing a streaming packet capture there is no size limit.
Page 223: Parameter Overview
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Parameter Overview Status - General Field General Status - General IP address IP address of the Spectralink IP-DECT Server. NTP Server IP address of the NTP Server. Time Time and date information.
Page 224: Status - Logs
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field NTP (Network Time Protocol) OK if the latest communication with the NTP server was suc- cessful. Status - Logs Field Message Log Display filter From the Display filter list you can select between emer- gency, critical, error, warning, notice or info depending on the logs you want to see.
Page 225: Status - Wireless Server
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Status - Wireless Server Field Wireless Server Status - General Firmware version Wireless Server firmware version. E.g. 59015 System ARI E.g. 1005354651 Wireless Server Status - License information License max users E.g. 30 License features E.g.
Page 226: Status - Network Diagnose
For more information, see also "Recommended Network Con- figuration" on page 85. IP addr Enter the IP address of the Spectralink IP-DECT Server. Netmask Enter a new network mask. Contact your system administrator for more information. Gateway Enter the IP address of the default gateway.
Page 227 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting General Configuration - IPv6 Method (Optional) Default value: Disabled If not using IPv4, select Static to set the following settings manually: IPv6 address, Subnet Prefix Length, Default Gate- way, Primary DNS Server, and Secondary DNS Server.
Page 228 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Server (Optional) Enter the IP address of the NTP server from which the system will obtain the current time. Time zone (Optional) Select the wanted time zone. The time zones include daylight saving times.
Page 229 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Scope (Optional) Scope of syslog settings. If set to all, the settings will override any local settings on e.g. connected base stations. If set to server only, these settings will only apply to the server.
Page 230: Configuration - Wireless Server
Default value: Default (250 mW) Note: It is possible to define a TX power value for a spe- cific base station (Administration > Base Station). Wireless Server Configuration - Media resources (Not relevant to the Spectralink IP-DECT Server 200/400) Allow new (Optional) If enabled, new media resources are allowed to connect to the server.
Page 231 PCS17Fa or newer to connect. If not enabled, the connection will be encrypted if the media resource supports encryption. Wireless Server Configuration - Base stations (Not relevant to the Spectralink IP-DECT Server 200. Allow new (Optional) If enabled, new base stations are allowed to connect to the server.
Page 232 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Multicast TTL (Optional) The TTL is used to limit the propagation of the multicast packets across routers. Default value: 1 Note:The TTL is configurable and it is possible to change the value according to network topology. For more inform- ation, see vendor specific documentation.
Page 233 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Wireless Server Configuration - Handsets (Not relevant to the Spectralink IP-DECT Server 200. Handset sharing (Optional) Enabled by default when Handset Sharing License is loaded. (Only visible if license loaded) Disable this, if handset sharing is not to be allowed.
Page 234 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Call forward unconditional - enable Enable call forward unconditional by dialing this code (Optional) (*21*), including the desired extension. E.g.: *21*$# Note: It is possible to change the code *21* on the Spec- tralink IP-DECT Server to fit your standard.
Page 235: Configuration - Media Resource
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuration - Media Resource Field Media Resource Configuration - Media resource Enable internal If enabled, the internal media resource will start up and con- nect. If disabled, CPU power is increased. Additional media resource will take over then, if installed.
Page 236: Configuration - Security
Allow remote logging If enabled, remote logging is allowed. (Optional) Remote logging allows for Spectralink debug tools to extract debug information from the unit. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 237: Configuration - Certificates
If enabled, users passwords are prevented from being included exported data (Optional) when data are exported from the Spectralink IP-DECT Server- ,e.g. when exporting the user list to XML files or CSV files. Note: Enabling this will exclude the user database from full sys- tem backups.
Page 238: Configuration - Sip
Setting SIP Configuration - General Local port Enter the local port number. The local port is the port on which the Spectralink IP-DECT Server listens for incoming SIP-signalling. The default local port number is 5060. Transport Transport mechanism used for SIP messages.
Page 239 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Max forwards The maximum number of proxies outgoing messages are allowed to traverse. Default value: 70 Client transaction timeout(msec) Client transaction time-out. This controls timer B and F as specified in RFC3261. Increase this to eliminate time out errors or decrease it to reduce fail over time.
Page 240 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting SIP Configuration - Proxies Proxies (Optional) Priority: The priority for using this proxy. Possible Value 1-4. Weight: The weight for using this proxy if more proxies have the same priority.
Page 241 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Subscription expire(sec) Enter the number of seconds before MWI subscription will be renewed. Default value: 3600 sec SIP Configuration - Media Packet duration(msec) Packet duration for transmitted RTP Packets. Possible values: 10, 20 or 40 msec.
Page 242 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Include lifetime in SDES offers Handles the RFC 4568 SRTP lifetime key parameter in SDP (Only visible if Security (TLS, offers. SRTP) License is loaded) Default value: Disabled (Optional) Include MKI in SDES offers (Only...
Page 243: Configuration - Redundancy
The UUID must be reset when a master Spectralink IP-DECT Server 6500 is changed to a backup Spectralink IP-DECT Server 6500, or when a backup Spectralink IP-DECT Server 6500 is moved to another solution.
Page 244: Configuration - Provisioning
Redundancy Configuration - Settings Failover time(sec) Enter value for failover time. Failure time is the time in seconds from the Spectralink IP- DECT Server detects a failure, until it initiates a failover oper- ation and cause the other peer to take over.
Page 245 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting If using Static for obtaining the URL of the provisioning server, enter an URL. Accepted format of URL is: [<protocol>://[<user- name>:<password>@]]<host>[:<port>][/<path>] Examples: 10.0.0.10 tftp://provisioning.test.com ftp://192.168.0.1 ftp://user:password@provisioning.example.com http://server.example.com/boot. https://server.example.com:10443/boot For more information about protocols and , see "Protocol" on page 1.
Page 246 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Provisioning Configuration - Users Import Enable. If enabled, this will make automatic update possible. Provisioning Configuration - Firmware Wirelesss Server (Only relevant to Enter name of firmware image file. Must match file name on Spectralink IP-DECT Server 200) provisioning server.
Page 247: Configuration - Import/Export
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Configuration - Import/Export Field Import/Export - Export configuration Export Click Save, if you want to export the configuration file. Save the configuration file. Import/Export - Import configuration Import Click Browse, if you want to search for a configuration file to be imported, select the relevant file, and then click Load.
Page 248: Users - List Users - User
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Users - List Users - User Field Setting User - DECT device Model After registration of user and subscription of handset, this field will contain information about the handset model. E.g. Spectralink7742...
Page 249 A standby text is a fixed label shown in the top left part of the screen on the DECT handset when in idle state. Note: This feature is only available if Spectralink DECT hand- sets are being used. If third party DECT handsets are being sub- scribed, this feature is not supported.
Page 250 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting User - Features Call forward unconditional A Call Forward Unconditional (an extension to forward calls to) (Optional) can be added/removed via the web based Administration Page. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 251: Users - List Devices - Device
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Users - List Devices - Device Field Setting Device - DECT device Model After registration of user and subscription of handset, this field will contain information about the handset model. E.g. Spectralink7742...
Page 252: Users - List User - Handset Firmware Update
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Device - User Username / Extension If the handset is linked to a specific user, the text field will hold the extension number of that user and the Username / Exten- sion link is active.
Page 253: Users - Import/Export
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Users - Import/Export Field Setting Import/Export Users - Import user data CSV format If you want to import user data, browse for the CSV file to import, and click Load. To be able to import the data correctly, the CSV file must con- tain certain information and punctuation.
Page 254: Administration - License
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Administration - License Field Licenses - Load license License Copy the provided license key from your email, paste it in the License field, and then click Load to load the license. For more information about ordering licenses, see "Ordering...
Page 255: Administration - Media Resource - Media Resource
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Administration - Media Resource - Media Resource Field Media Resource - General IP address (Read only) Current IP address of the media resource. Description (Optional) Enter a description. It is recommended to use a description of the physical loc- ation.
Page 256: Administration - Base Station - Base Station
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Administration - Base Station - Base Station Field Base Station - General IP address (Read only) Current IP address of the base station. Description (Optional) Enter a description. It is recommended to use a description of the physical loc- ation.
Page 257 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field External antenna mode (Optional) Determines which antenna(s) are used when an external antenna is connected. Possible values: Use Internal & external antenna, Use internal antenna only or Use external antenna only.
Page 258: Administration - Clusters - Cluster
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Administration - Clusters - Cluster Field Cluster - General Name Enter a name for the cluster. E.g. Site A, Site B, Site C. 14215700-IG, Edition 8.0 April 2018, Original document...
Page 259: Administration - Phonebook
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Administration - Phonebook Field Setting Phonebook Configuration - Disabled Disabled As default, phone book configuration is disabled. You can configure the server to retrieve phone book data using LDAP server or by import of phone book data from a CSV file.
Page 260: Administration - Backup
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Filter (Optional) Enter the filter used for the LDAP query. The (objectClass- s=person) filter can be used successfully in most cases. Attributes Enter the LDAP attributes you want to query the LDAP for, sep- arated by a comma.
Page 261: Firmware - Wireless Server
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Firmware - Wireless Server Field Setting Update firmware - Firmware file Click Browse to browse for the relevant firmware file. Enable the Use firmware as default check box if you want the server firmware as default for all base stations and media resources (recommended).
Page 262 Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Update media resource firmware - Automatic Enable (Optional) Default value: Disabled Enable this, if you want to make automatic update possible. The media resources will be automatically updated using the default firmware.
Page 263: Firmware - Base Station
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Firmware - Base Station Field Setting Update base station firmware - Default Information about default firmware file version (PCS) - if a firm- ware file has been uploaded. Note: Once uploaded, default firmware will remain on the server until overwritten.
Page 264: Firmware - Handset
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide Field Setting Click Save. Update base station firmware - Manual Firmware file (Optional) The firmware file can be either a previously uploaded default firmware file, or a new firmware file chosen. A new firmware file has to be a valid firmware file with the extension .bin.

This manual is also suitable for:

Ip-dect 6500 Ip-dect 400

SpectraLink IP-DECT 200 Installation And Configuration Manual

About this Guide

About DECT

Spectralink IP-DECT Server Solution

Licenses

Installation Requirements

Installation Prerequisites

About ARI and IPEI Identification

Installing the Spectralink IP-DECT Server

Installing the Spectralink IP-DECT Server 6500 and Spectralink DECT Media Resource

Installing the Spectralink IP-DECT Base Station

Installing the Spectralink DECT Repeater

Using the Spectralink IP-DECT Server 200/400 and Spectralink IP-DECT Base Station with External Antenna

Tralinkip-DectbasestationwithexternalAntenna 78

Configuration Steps Overview

Configuring the Spectralink IP-DECT Server/Spectralink DECT Media Resource Solution

Administration of Spectralink IP-DECT Base Stations

Registering Users and Subscribing Spectralink DECT Hand- Sets

Handset Management

System Management

Messaging over MSF

Redundant System Configuration

Configuring Corporate Phone Book/Directory

Handset Sharing

Installing the Spectralink IP-DECT Server

Product Compatibility

Troubleshooting

Parameter Overview

Quick Links

Related Manuals for SpectraLink IP-DECT 200

Summary of Contents for SpectraLink IP-DECT 200
