Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
Field
Device - User
Username / Extension
Displayname (Optional)

Users - List User - Handset firmware update

Field
Handset firmware update - Options
Update load
Start time
Firmware file
14215700-IG, Edition 8.0
April 2018, Original document
Setting
If the handset is linked to a specific user, the text field will hold
the extension number of that user and the Username / Exten-
sion link is active.
Note: Clicking on the link will take you to the User profile of the
linked handset.
If the user is not linked to a handset, the link is inactive and there
is no extension number in the text field.
After creation of user, this field will contain information about
user name (e.g. caller ID).
E.g. John Doe in John
Doe<sip:1234@example.org>
Setting
Select relevant upload capacity. The load corresponds to the
number of maximum simultaneous updates.
Possible values: Low, Medium or High.
Default value: Medium
Default value: Now
If you want to upload later, select an appropriate time within
the next 24 hours.
The firmware file can be either a previously uploaded default
firmware file, or a new firmware file chosen. A new firmware
file must be a valid firmware file with the extension .bin.
Select either Default or Upload.
