Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
Field
Send all messages to current
registrar (Optional)
Registration expire(sec)
Handset power off action
(Optional)
Max forwards
Client transaction timeout
(msec)
SIP type of service (TOS/Diff-
serv)
SIP 802.1p Class-of-Service
GRUU (Optional)
Use SIPS URI (Optional)
14215700-IG, Edition 8.0
April 2018, Original document
Setting
If enabled, all non-REGISTER requests to the current
registrar will be sent, when more proxies are available.
The maximum time between re-registrations. The regis-
trar can signal a shorter time-out.
Default value: 3600 sec
Action performed when a handset is turned off.
Possible values: Ignore or De-register.
If De-register is selected, the handset will de-register
when turned off.
Default value: Ignore
The maximum number of proxies outgoing messages are
allowed to traverse.
Default value: 70
Client transaction time-out. This controls timer B and F
as specified in RFC3261. Increase this to eliminate time
out errors or decrease it to reduce fail over time.
Default value: 16000 msec
TOS/Diffserv used for SIP signaling. Entered in decimal.
Default value: 96 (AF - Assured Forwarding)
This is the 802.1p PCP and must be between 0 and 7.
The setting requires VLAN tagging.
Default value: 3
If enabled, Globally Routable User Agent URIs are sup-
ported.
Default value: Enabled
Normally, SIP communication on a TLS connection uses
the SIPS: URI scheme.
Disabling this option causes the Wireless Server to use
the SIP: URI scheme with a transport=tls parameter for
TLS connections.
Default value: Disabled
102
