Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide

Configuring SIP and IP-PBX Settings

You can configure general SIP settings, authentication information, DTMF signalling, message wait-
ing indication and media for the IP-PBX through the web based Administration Page.
This section describes how to configure general SIP settings and register for SIP.
For more information about IP-PBX specific settings, see the relevant Interoperability Guides.

To Configure SIP Settings

To configure SIP settings from the web based Administration Page:
1. Click Configuration, and then click SIP.
2. On the SIP Configuration page, enter the following data:
Field
SIP Configuration - General
Local port
Transport
DNS method
Default domain
Register each endpoint on sep-
arate port (Optional)
14215700-IG, Edition 8.0
April 2018, Original document
Setting
Enter the local port number.
The local port is the port on which the Spectralink IP-
DECT Server listens for incoming SIP-signalling.
The default local port number is 5060.
Transport mechanism used for SIP messages.
Possible values: UDP, TCP or TLS.
Note: If TLS is used as SIP Transport Method, it is neces-
sary to import host certificate and CA certificates into the
server. For more information, see
tificates" on page 116.
Used for looking up the destination of SIP messages.
Possible values: A records or DNS SRV.
Used for SIP registration. Enter the name of the domain.
Note: If no user specific domain is configured under a
specific user, the handsets registered on the Spectralink
IP-DECT Server will use the default domain as the
domain part of the SIP URI;
e.g. John Doe <sip:1234@example.org>
If only one SIP PBX is used and no domain is available,
enter the IP address of PBX here.
If enabled, separate local ports for each endpoint are
used, instead of the global local port.
"Configuring Cer-
101
