User Manual Roth EnergyLogic Touchline/Wireless
Parameter descriptions
Parameter
P-63
P-64
96
Description
Select control of pump "local" or "Master-wireless connection module".
This parameter can only be configured when several wireless connection modules
communicate wirelessly.
●
Factory settings:
●
Options
–
0: Pump output is configured as local pump. The pump will be switched on
only when heating or cooling demand is caused by one of the channels of by
the wireless connection module to which the pump is connected. The pump
will not be switched on when demand is caused by another wireless connec-
tion.
–
1: Only the pump output of the Master-wireless connection module is activat-
ed. When demand is caused by any channel ate any wireless connection
module then the pump connected to the Master wireless connection module
will be switched on.
Operation
►
Press sensor button
►
Press sensor button
►
Select one of the following options:
–
Press sensor button
next parameter P-64.
–
Press sensor button
lected parameter.
Select NC or NO function of thermal actuators.
Option "NC" (normally closed) should be selected for thermal actuators that open
the valve when the actuator is connected to power. Option "NO" (normally open)
should be selected for thermal actuators that close the valve when the actuator is
connected to power.
●
Factory settings: Option "0"
●
Options
–
0: normally closed NC
–
1: normally open NO
Operation
►
Press sensor button
►
Press sensor button
►
Select one of the following options:
–
Press sensor button
next parameter P-65.
–
Press sensor button
lected parameter.
. The display shows 0.
or , to select option 0, 1, or 2.
, to save the changed settings. The display shows the
, to interrupt the procedure. The display shows the se-
. The display shows 0.
or , to select 0 or 1
, to save the changed settings. The display shows the
, to interrupt the procedure. The display shows the se-
P100011294 E
