7.6

Time programs

7.6.1

Overview of the three time programs

7.6.2

Factory settings time program

1 1 2
06:00...23:00 OFF
Fig. 42: Factory settings time programs
NOTE
P100011294 E
The wireless connection module has three different types of time programs
that can be changed. The time programs are the same for all room thermo-
stats.
●
I: One profile for all weekdays (one profile)
Profile symbol:
Time program I has just one profile with three switched-on periods that are
the same for every day.
●
II: One profile for working days and one profile for the weekend (2 profiles)
Profile symbols: working days:
With time program II one can distinguish between "working days" and
"weekends", each with three switched-on periods.
●
III: One profile for each weekday (7 profiles)
Profile symbols: Monday
The most advanced time program can be made with time program III: it is
possible to create different profiles for every weekday, each with three
switched-on periods.
2 3 3 1 1
06:00...08:30 16:30...23:00
—
06:00...23:00 OFF
It is possible to enter one to three switched-on periods. If only one
switched-on period is entered, then during programming the second period
is shown at the display as "OFF" and the third is not shown at all. When a
second period is entered, then the third period will appear as "OFF", and
can be programmed too.
User Manual Roth EnergyLogic Touchline/Wireless
1 2 3 4 5 6 7
1 2
, Tuesday
1
2 2 3 3 1
06:00...08:30 11:30...13:30
06:00...08:30
06:00...08:30
OFF
06:00...08:30
06:00...08:30
06:00...23:00 00:00...00:00
—
06:00...23:00
Commissioning and operation
, weekend:
3 4 5 6
, ... Saturday , Sunday
2 6
1 2 2 3 3
16:30...23:00
11:30...13:30 16:30...23:00
11:30...13:30 16:30...23:00
11:30...13:30 16:30...23:00
11:30...13:30 16:30...23:00
00:00...00:00
00:00...00:00 00:00...00:00
7
7
