14.2.4

Outputs

Max. number of thermal actuators
Maximum current per channel
Outputs for thermal actuators
Configurable output for C/O or burner
start
Relays for pump output
Output 24 V AC
14.2.5

Radio power data

Data transmission
Transmission power
14.2.6

Environmental conditions

Ambient temperature
Ambient humidity
Storing and transport temperature
Ingress protection (IP Code)
P100011294 E
User Manual Roth EnergyLogic Touchline/Wireless
●
4-channel: 6 (2 channels / 2 actuators, 2 channels / 1 actuator)
●
8-channel: 12 (4 channels / 2 actuators, 4 channels / 1 actuator)
●
12-channel: 18 (6 channels / 2 actuators, 6 channels / 1 actuator)
●
250 mA
●
24 V Triac-outputs
●
NO (normally open) / NC (normally closed), configurable
●
PWM- or On/Off-control
●
Shortcut protected
●
230 V / 2.5 A (1) A inductive
●
Potential free
●
Without time delay and after-run time
●
230 V / 2.5 A (1) A inductive
●
Potential free
●
2 min delay
●
5 min after-run time
●
24 V / 100 mA
●
Room control network: max. 10 min
●
System network: max. 3 min
< 13 mW
0 to +55 °C
5 to 80 % r.F.
–25 to +60 °C
IP 20 (EN 60529)
Technical data
