User Manual Roth EnergyLogic Touchline/Wireless
Accessories
13.2.5

Assign the external repeater to a wireless connection module

NOTE
13.2.6 Test addressing of the wireless connection modules "Slave" and
"Master"
NOTE
110
The system comprises a wireless connection module "Master" and up to four
wireless connection modules "Slave". Since the distance is too far, the wire-
less connection modules "Slave" cannot be assigned to the wireless connec-
tion module "Master".
The external repeater is installed between the wireless connection module
"Master" and the wireless connection module "Slave". The repeater is installed
and supplied with power. The green LED lights up at the external repeater.
The distance between the external repeater and a wireless connection module
must not exceed 30 m.
►
Press push button System of the wireless connection module "Master"
until the LED System blinks.
►
Press the push button at the external repeater for 5 seconds. The green
LED at the repeater blinks.
►
Press push button System of the wireless connection module "Slave" until
the LED System blinks. The green and yellow LEDs on the external re-
peater light up.
►
At successful addressing:
– the LED System of the wireless connection module "Slave" lights up.
– the LED System of the wireless connection module "Master" changes
from blinking to off.
– the LED System of the wireless connection module "Master" lights up
as soon as the first communication with the wireless connection module
"Slave" has been built up.
If the red LED starts to flash during addressing, the wireless connection
module will not respond. The distance between repeater and wireless con-
nection module may be too large.
If the LED System is lit on the wireless connection modules "Slave" and
"Master" each, the wireless connection module "Slave" is assigned to a wire-
less connection module "Master". If the LED System is not lit, this wireless
connection module is too far away from the external repeater.
No further tests are required. If required, check the addressing by installing
a jumper across terminals 17 and 18 (C/O input) at the wireless connection
module "Master". The wireless connection module "Master" will switch to
cooling mode and forward the signal to the wireless connection module
"Slave". After no more than 3 minutes, the LED "Cool" will light up blue.
P100011294 E
