Commissioning and operation

Steps during
commissioning
7.1

Addressing

NOTE
P100011294 E
The commissioning of the control system comprises the following steps:
►
Execute the addressing between wireless connection module and wireless
room thermostats.
►
Test addressing.
►
If applicable: set time and date with one wireless room thermostat.
►
Configure wireless connection modules and wireless room thermostats.
During addressing a wireless room thermostat is assigned to a radio channel.
The following combinations between a wireless connection module and a
wireless room thermostat are possible:
●
Address one wireless room thermostat to one radio channel.
●
Address one wireless room thermostat to several radio channels.
●
Address one wireless room thermostat or several wireless room thermo-
stats to one radio channel (sensor mode)
●
Address up to 5 wireless connection modules to each other.
●
Combine several radio channels into one zone.
●
Up to 12 wireless room units can be addressed to one wireless connection
module, 4-, 8- or 12 channel version.
●
One wireless room thermostat and up to four wireless room thermostats in
sensor mode can be addressed to one channel. The additional wireless
room thermostats have to be set into sensor mode before addressing to
the channel.
●
Each wireless connection module can be divided into up to 3 zones.
Every wireless connection module can be assigned up to 12 wireless
room thermostats (room thermostats, window contacts, etc.). If you want
to set up a system using more than 12 wireless room thermostats, you
can distribute the wireless room thermostats among several wireless
connection modules. If you need, for example, 12 wireless channels, you
can implement this using a wireless connection module with 4 wireless
channels and a wireless connection module with 12 wireless channels. In
this configuration, you can connect up to 24 wireless room thermostats.
