User Manual Roth EnergyLogic Touchline/Wireless
Plant examples and communication

16.2 Plant examples with up to five wireless connection modules

124
7
C
Slave
CH 1
B
Slave
CH 1
A
Master
CH 1
Fig. 64: Example with three wireless connection modules
A Basement
1 Zone 1, basement
2 Zone 2, basement
3 Single addressing
B 1. Floor
4 Zone 1 with average temp. building
5 Zone 2 with setpoint sharing
6 Zone 3
8
CH 2 CH 3 CH 4 CH 5
4
SENS SENS
P-46 P-46
CH 2 CH 3 CH 4 CH 5
1 2
CH 2 CH 3 CH 4 CH 5
C 2. Floor
7 Radio channel group 1
8 Radio channel group 2
9 Single addressing
CH 1...CH 8: radio-channels
9
CH 6 CH 7 CH 8
5 6
P-46 P-46
CH 6 CH 7 CH 8
3
CH 6 CH 7 CH 8
P100011294 E
