13.2.3

Test the external repeater's radio connection

NOTE
13.2.4

Delete the external repeater's radio connection

P100011294 E
►
Press the sensor buttons
taneously for 5 seconds. The green and yellow LEDs on the external re-
peater light up. The LED CH 1 at the wireless connection module stops
blinking.
The display of the wireless room thermostat is activated (operation mode).
The symbol is displayed.
The wireless room thermostat is assigned to radio channel CH 1 via the
repeater.
Perform the following steps to find out whether the radio connection to the
wireless connection module is running via the external repeater and whether
the wireless connection module and the wireless room thermostat are as-
signed correctly.
►
The display of the wireless room thermostat shows the symbol
room thermostat is assigned to a wireless connection module.
►
Press the sensor buttons
simultaneously. The display of the wireless room thermostat shows "Pair" –
"Test" as long as the LED of the wireless connection module is lit. The yel-
low LED at the external repeater goes out and the green LED blinks quick-
ly.
►
On the wireless connection module the LED of the assigned channel is lit.
If the wireless room thermostat is assigned to more than one channel then
all assigned channel LEDs are lit.
►
The LED goes out or the LEDs go out after 5 seconds.
The addressing has been tested.
If the green LED blinks quickly at the external repeater during the test,
there is a proper wireless connection from the wireless room thermostat to
the wireless connection module via the external repeater.
If the green LED at the external repeater is lit during the test, there is direct
wireless connection between the wireless room thermostat and the wire-
less connection module. The wireless room thermostat is in range of the
wireless connection module.
►
Press the push button at the external repeater for 10 seconds.
►
After a short time, the yellow LED goes out. The green LED starts to blink.
After another 5 seconds, all LEDs will blink.
►
Delete all LEDs at the external repeater The green LED lights up again
after a moment.
The addressing is deleted. You may re-address the external repeater.
User Manual Roth EnergyLogic Touchline/Wireless
and of the wireless room thermostat simul-
and of the room thermostat for 5 seconds
Accessories
. The
