User Manual Roth EnergyLogic Touchline/Wireless

Electrical connections

6 Electrical connections
6.1

Safety

DANGER
6.2

General wiring notes

DANGER
38
Danger to life from electrical voltage!
Contact with live parts is an immediate danger to life.
Damage to the insulation or individual components can be life threatening.
– When insulation is damaged turn off power immediately and arrange for
repair.
– Only a qualified electrician should perform work on the electrical system.
– Before any work, disconnect the wireless connection module and the
peripheral devices from the mains and secure against reactivation. Test
for absence of voltage!
– Type Y attachment according to EN 60730
– Moisture and dust should be kept away from energized parts. Moisture
or dust can cause a short circuit.
Danger from electric shock!
Improper wiring may be potentially fatal.
– Perform wiring according to connection chart.
– Insert wires into the terminals completely to the stop.
– Only use the prescribed core cross-sections.
– Observe the prescribed dimensions for stripping.
– If wire-end ferrules with plastic collar are used, observe the prescribed
dimensions for plastic collars.
– Do not use twin wire-end ferrules.
P100011294 E
