User Manual Roth EnergyLogic Touchline/Wireless
Electrical connections
Install cover
Fig. 41:
Install cover and connect power supply
50
►
Put on the cover as shown below
►
Insert the plug from the transformer into the outlet.
►
At the wireless connection module the Power LED must light.
1
3
4
Power
2
click
P100011294 E
